CONNECTION DIAGRAMS SENTRY
51 Back to table of contents
CH1 CH2
CH1
MODE
CH2
Jokab Safety
USR10SENTRY
Jokab Safety
USR10SENTRY
Jokab Safety
SSR10SENTRY
Note: It is the responsibility of the machine builder to make a risk assessment and make sure that the appropriate functional safety levels are achieved.
