CONNECTION DIAGRAMS SENTRY
9 Back to table of contents
A
B
Relay output
A
B
A
B
Jokab Safety
BSR11/BSR10SENTRY
Jokab Safety
BSR11/BSR10SENTRY
Jokab Safety
BSR11/BSR10SENTRY
Transistor output
Negative voltage
Transistor output
Positive voltage
A
B
Jokab Safety
BSR11/BSR10SENTRY
Transistor output
with 0V supervison/control
Positive voltage
Note: It is the responsibility of the machine builder to make a risk assessment and make sure that the appropriate functional safety levels are achieved.
