1ZSC000498-ABH en, Rev. 1 | Maintenance guide BUE/BUL2 11
Operation counter
Roller
Notch
Cam disc
Brake arm
Geneva wheel
(Grease)
(Grease)
Adjusting
screw
Holding
contact
Brake disc
Multi-position switches
Limit switch
Bracket
Toothed belt
(Grease)
Fig. 4. Mechanical design of motor-drive mechanism, type BUL2.
(Grease)
