16 Maintenance guide BUE/BUL2 | 1ZSC000498-ABH en, Rev. 1
NOTE: The small bevel gear
for the position indicator shaft
must be greased.
Fig. 8. Lubrication points, type BUE.
Grease
Grease
Oil
Grease
Grease
Grease
Oil
