ABB C13

2CMC486004M0201 13 C13
Revision: A User Manual
Installation
3.3.1 Wiring Diagrams
4-wire connection
The following diagram shows a 4-wire connection of a direct connected 3-phase
meter:
3.3.1.1 Outputs
Fixed, 1 output
9
1
34
6
7
12
10
