ABB C13 User Manual

2CMC486004M0201 19 C13
Revision: A User Manual
User Interface
Set menu
The set menu is used to set different options in the meter. The set menu is reached
by using the long press when located in the view menu. The following choices are
available in the set menu, see table below.
Set alarm menu
When choosing Exit, the menu will return to the view menu. When choosing Out-
put, the following choices will be available.
CRC Part 1 N/A 4 N/A N/A 0000 FFFF
CRC Part 2 N/A 4 N/A N/A 0000 FFFF
Error Er <numerical
value>
4 N/A N/A N/A N/A
Choice in menu Output on
display
No. of
digits
No. of
decimals
Unit Min.
value
Max. value
Choice in menu Output on display
Output 
Exit 
Choice in menu Output on display Explanation
Alarm power 
VV
By choosing this option, the
alarm will be set with regards to
the measured power.
Alarm voltage 
V
By choosing this option, the
alarm will be set with regards to
the measured voltage on
Phase 1.
Alarm voltage 
V
By choosing this option, the
alarm will be set with regards to
the measured voltage on
Phase 2.
Alarm voltage 
V
By choosing this option, the
alarm will be set with regards to
the measured voltage on
Phase 3.
Alarm current 
A
By choosing this option, the
alarm will be set with regards to
the measured current on Phase
1.
Alarm current 
A
By choosing this option, the
alarm will be set with regards to
the measured current on Phase
2.
Alarm current 
A
By choosing this option, the
alarm will be set with regards to
the measured current on Phase
3.
