13
7 BASIC CONFIGURATION LEVEL…
…7.1.5 Divert Page
Note.
2
nd
RT and RT Deviation – the hot product temperature can be measured by a single or dual RTD. For the dual RTD, the primary
input is always the one displayed as ‘Hot Product’.
The secondary RTD enables a self-check facility which can be used to maintain the integrity of primary and secondary
resistance thermometer devices. Any imbalance between the first and second RTD greater than the trip level entered in the
appropriate scroll automatically causes the flow to divert, regardless of the primary temperature measurement.
Single
Divert
Multi
Divert
rt-dVt
EnbL-Y
N
SEtUP
dIVErt
2nd rt
----
rt-dEV
----
PANL-2
OFF
2nd-rt
UNItS
COLD P
d-OdE
-ULtI
SINGLE
dIVErt
----
2d-SrC
----
1952/3
CIP.Src
----
2nd rt
Enbl y
n
Single
RT
OP-LEV
EnbL-Y
n
Page Header – Set Up Divert Page
Second RT Enable
Enables dual RTD selection (provided the auxiliary input module is fitted).
Second RT Value
If dual RTD values have been selected, the temperature value for the second RTD is displayed.
RT Deviation Trip Value
Set the deviation level (1
st
–2
nd
RTD value) required for difference condition. If (1
st
– 2
nd
RTD)
>
rt–deV the deviation trip condition is true.
RT Divert Enable
Enables diversion if the above condition is true.
Panel 2 (Record Faceplate) Set Up (displayed with model 1951 only – see fig. 2.3)
Panel 2 Upper Display Panel 2 Lower Display
OFF Blank Blank
2nd-rt Second RT value (1st RT – 2nd RT) value
UNItS Hot product units Divert temp. units
COLD P Cold product value Blank
Divert Mode
The instrument can be configured to operate in one of two divert modes:
MULtI – Up to eight divert set points can be set.
SINGLE – One divert set point can be set.
Divert Number
Select the divert setting required:
1, 2, 3, 4, 5, 6, 7 or 8 (used with associated
Divert Set Point, Hot Water Set Temperature
and Set Point Source displays).
Caution. Do not change divert numbers during a process (only before or after).
Operator Level (Enable Divert Number Selection)
Allows the divert number to be selected at Operator level.
Secondary Divert Alarm Source
Diverts event pen on any assigned digital condition.
Cleaning in Place
Set digital source for CIP event.
continued on next page…
