CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | OI/FCB400/FCH400-EN REV. E 111
Menu / parameter Description
Input / Output / ...Dig.Out V1 / V2 / ...Setup Logic Output
Input / Output / ...Dig.Out V3 / V4 / ...Setup Logic Output
Logic Output Action Selection of binary output function.
See description ‘„Input / Output / ...Dig.Out 41 / 42 / ...Setup Logic Output’.
Active Mode Select switching properties for the binary output.
Input / Output / ...Dig.Out V1 / V2 / ...Alarm Config
Input / Output / ...Dig.Out V3 / V4 / ...Alarm Config
General Alarm Select error messages signaled via the binary output V1 / V2 or V3 / V4.
Only if the parameter ‘Logic Output Action’ is set to Alarm Signal.
Qm Massflow Max
Qm Massflow Min
Density Min
Density Low Check
Sensor Signal Min
Driver Output Max
Input / Output / ...Dig.In V1 / V2
Input / Output / ...Dig.In V3 / V4
Function Select a function for the digital input.
• Off: No function.
• Reset all Totalizer: Counter reset for all counters (forward flow, reverse flow and difference totalizer)
• Stop all Totalizer: External counter stop for all counters (forward flow, reverse flow and difference totalizer)
• Auto. Zero Adjust:Start external zero point balancing.
• Set Flowrate to zero: Sets flow measurement to 0.
• Batchflow On / Off: Start / stop fill operation (only when FillMass function is activated).
• Dual Range Mass: Switchover Qm Max / Qm Max 2.
• Dual Range Volume: Switchover Qv Max / Qv Max 2.
• Submatrix 1 or 2: Switchover for concentration matrix (only when DensiMass function is activated).
Active Mode Select switching properties for the digital input.
Delay Time Selection of delay time for suppressing EMC faults on the digital input.
NOTICE
If the digital input has been configured with the function ‘Batchflow On / Off’ the pulse for starting the filling process
must fit at least for the set delay time!
