8 LME620-AI / PME120-AI / EAN823 / EBN853 / EBN861 ELECTRONIC UNIT | OI/PME/LME/EAN823/EBN853/EBN861-EN REV. E
… 2 Design and function
Device designs
EAN823
IP rating IP 66 in accordance with IEC 60529 / EN 60529
NEMA 4X in accordance with CAN / CSA22.2 No. 94
Humidity ≤ 95% annual average; condensation not permitted
Ambient temperature −25 to 55 °C (−13 to 131 °F)
Transport and storage temperature −25 to 70 °C (−13 to 158 °F)
Long-term storage temperature −25 to 40 °C (−13 to 104 °F)
Mounting position On vertical mounting plate, lateral cable gland, left
Vibration stress Maximum 150 Hz: acceleration: 1 g (in accordance with EN 60068-2-6, Table C.2)
Electrical connection Mains supply and connection cable to the control system through screw terminals.
Connection cable between electronic unit and actuator tightly fastened optionally to the electronic unit,
from the actuator side using a connector to the connection to the actuator. Available cable lengths 5 m
(16 ft), 10 m (32 ft) or 20 m (65 ft).
Maximum cable length for delivery without cable: 30 m (98 ft)
Weight 11 kg (24 lbs)
EBN853
IP rating IP 66 in accordance with IEC 60529 / EN 60529
NEMA 4X in accordance with CAN / CSA22.2 No. 94
Humidity ≤ 95% annual average; condensation not permitted
Ambient temperature −25 to 55 °C (−13 to 131 °F)
Transport and storage temperature −25 to 70 °C (−13 to 158 °F)
Long-term storage temperature −25 to 40 °C (−13 to 104 °F)
Mounting position On vertical mounting plate, lateral cable gland, left
Vibration stress Maximum 150 Hz: acceleration: 1 g (in accordance with EN 60068-2-6, Table C.2)
Paint 2-layer component epoxy (RAL 9005, black)
Electrical connection Mains supply via screw terminals; all other connections made via screw-type plug connectors
Connection cable between electronic unit and actuator tightly fastened to the electronic unit, from the
actuator side using a connector to the connection to the actuator. Maximum cable length 100 m (328 ft).
In actuators in explosion-proof design, the connection cable is tightly fastened to the actuator without a
connector through the screw terminals.
Optional, loose cable set supplied acc. to length requirements
Weight 11 kg (24 lbs)
