Chapter 2 – Overview
2-4 Installation and Start-up Guide for NBRA-6xx
Table 2-1 ACS 600 ratings for resistor braking.
ACS 600
Type
Braking
Chopper
Type
Braking Resistor(s)
Cable
(Copper)
Braking
Power
Type
R
[ohm]
E
R
[kJ]
P
Rcont
[kW]
No. of
Elements*
A
[mm
2
]
P
BRmax
[kW]
400 V a.c. Units
-0005-3 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 5.0
-0006-3 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 6.2
-0009-3 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 8.3
-0011-3 NBRA-653 SACE15RE22 22.0 420.0 2 4 3x6+6 11.0
-0016-3 NBRA-653 SACE15RE22 22.0 420.0 2 4 3x6+6 14.4
-0020-3 NBRA-654 SACE15RE13 13.0 435.0 2 4 3x6+6 19.7
-0025-3 NBRA-654 SACE15RE13 13.0 435.0 2 4 3x6+6 26.9
-0030-3 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 33.2
-0040-3 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 39.0
-0050-3 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 52.8
-0060-3 NBRA-656 SAFUR80F500 6.0 2400 6 12 3x35+16 65.6
-0070-3 NBRA-656 SAFUR125F500 4.0 3600 9 18 3x35+16 79.5
-0100-3 NBRA-657 SAFUR125F500 4.0 3600 9 18 3x70+35 94.2
-0120-3 NBRA-657 SAFUR200F500 2.7 5400 13.5 27 3x70+35 128.3
-0140-3 NBRA-658 SAFUR200F500 2.7 5400 13.5 27 see Table 2-2 154.5
-0170-3 NBRA-658 2xSAFUR125F500 2.0 7200 18.0 2x18 see Table 2-2 190.7
-0210-3 NBRA-658 2xSAFUR210F575 1.70 8400 21.0 2x21 see Table 2-2 229.5
-0260-3 NBRA-659 2xSAFUR200F500 1.35 10800 27.0 2x27 see Table 2-2 282.3
-0320-3 NBRA-659 2xSAFUR180F460 1.2 12000 30 2x30 see Table 2-2 352.8
-0400-3 2xNBRA-658 2x(2xSAFUR210F575) 2x1.70 2x8400 2x21.0 2x(2x21) see Table 2-2 436.1
-0490-3 2xNBRA-659 2x(2xSAFUR200F500) 2x1.35 2x10800 2x27.0 2x(2x27) see Table 2-2 536.3
-0610-3 2xNBRA-659 2x(2xSAFUR180F460) 2x1.2 2x12000 2x30 2x(2x30) see Table 2-2 670.3
500 V a.c. Units:
-0006-5 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 6.3
-0009-5 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 7.8
-0011-5 NBRA-653 SACE08RE44 44.0 210.0 1 2 3x6+6 10.4
-0016-5 NBRA-653 SACE15RE22 22.0 420.0 2 4 3x6+6 14.0
-0020-5 NBRA-653 SACE15RE22 22.0 420.0 2 4 3x6+6 18.5
-0025-5 NBRA-654 SACE15RE13 13.0 435.0 2 4 3x6+6 25.2
-0030-5 NBRA-654 SACE15RE13 13.0 435.0 2 4 3x6+6 31.4
-0040-5 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 42.6
-0050-5 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 50.1
-0060-5 NBRA-655 SAFUR90F575 8.0 1800 4.5 9 3x25+16 62.6
-0070-5 NBRA-656 SAFUR80F500 6.0 2400 6 12 3x35+16 72.6
-0100-5 NBRA-656 SAFUR80F500 6.0 2400 6 12 3x35+16 88.4
-0120-5 NBRA-657 SAFUR125F500 4.0 3600 9 18 3x70+16 122.1
-0140-5 NBRA-657 SAFUR125F500 4.0 3600 9 18 3x70+16 147.3
-0170-5 NBRA-658 SAFUR200F500 2.7 5400 13.5 27 see Table 2-2 181.1
-0210-5 NBRA-658 SAFUR200F500 2.7 5400 13.5 27 see Table 2-2 220.7
-0260-5 NBRA-658 2xSAFUR125F500 2.0 7200 18.0 2x18 see Table 2-2 268.1
-0320-5 NBRA-659 2xSAFUR210F575 1.7 8400 21.0 2x21 see Table 2-2 335.0
-0400-5 NBRA-659 2xSAFUR200F500 1.35 10800 27.0 2x27 see Table 2-2 402.8
-0490-5 2xNBRA-658 2x(2xSAFUR125F500) 2x2.0 2x7200 2x18.0 2x(2x18) see Table 2-2 509.3
-0610-5 2xNBRA-659 2x(2xSAFUR210F575) 2x1.7 2x8400 2x21.0 2x(2x21) see Table 2-2 636.5
-0760-5 2xNBRA-659 2x(2xSAFUR200F500) 2x1.35 2x10800 2x27.0 2x(2x27) see Table 2-2 765.3
(continued)
