ABB PSTX Series Installation And Commissioning Manual

11
5
9
13
3
7
11
2
6
10
4
8
12
14
1 Introduction
2 Quick start
3 Description
4 Installation
5 Connection
6 Human machine interface (HMI)
7 Functions
8 Communication
9 Maintenance
10 Troubleshooting
11 Wiring and application diagrams
12 Third party licenses
13 Revision
14 Index
Softstarters Type PSTX
Installation and commissioning manual

ABB PSTX Series Specifications

General

Type	Softstarter
Rated operational voltage	208-690 V AC
Rated operational current	30-1250 A
Number of phases	3
Operating temperature	-25 to +60°C
Operating frequency	50/60 Hz
Overload protection	Yes
Protection class	IP20
Communication protocols	Modbus RTU, Profibus
Starting method	Voltage ramp, current limit
Stopping method	soft stop
Bypass contactor	Built-in
Display	graphical display
Rated control supply voltage	100-240V AC
