ABB REF 54 Series Technical Reference Manual, General

52
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
For technical data of the RTD/analog inputs, refer to Table 5.2.1-4 on page 90.
The parameters for the RTD/analog inputs are included in the parameter lists on the
CD-ROM “Technical Descriptions of Functions” (
refer to Section “Related
documents” on page 10).
5.1.9.1. Selection of input signal type
The general purpose RTD/analog inputs accept voltage-, current- or resistance-type
signals. The inputs are configured for a particular type of input signal by means of
the channel-specific “Input mode” parameters that can be found in the menu
Configuration/RTD1/Input #. The default value is “Off” which means that
the channel is not sampled at all, and the IN+, IN- and SHUNT terminals are at high
impedance state.
1) Two-wire measurement
2) Three-wire measurement
5.1.9.2. Selection of input signal range
For each measuring mode, a separate parameter is provided for choosing between
the available measurement ranges. These channel-specific parameters, which can be
found in the menu Configuration/RTD1/Input #, are named “Voltage
range”, “Current range”, “Resistance range” and “Temperature range”. All range
parameters can be set but only one is used. The value of the “Input mode” parameter
determines which range parameter is used. The “Temperature range” parameter also
defines the sensor type to be used, for example PT100.
REF 541/REF 543 + RTD1
RTD/analog inputs RTD1_6_AI1
RTD1_6_AI2
RTD1_6_AI3
RTD1_6_AI4
RTD1_6_AI5
RTD1_6_AI6
RTD1_6_AI7
RTD1_6_AI8
Parameter Values Default
Input mode 0 = Off Off
1 = Voltage
2 = Current
3 = Resistance 2W
1)
4 = Resistance 3W
2)
5 = Temperature 2W
1)
6 = Temperature 3W
2)
