ABB REF 54 Series Technical Reference Manual, General

72
1MRS750527-MUM
Feeder Terminal
Technical Reference Manual, General
REF 54_
Class 2 event count 1...32 1 Event count for spontaneous event
reporting for class 2
Class 3 event delay 0...1000 [s] 1 Delay for spontaneous event reporting
for class 3
Class 3 event count 1...32 1 Event count for spontaneous event
reporting for class 3
Unsolicited reporting
mode
2)
0...3
[0=unsolicited responses
are disabled;
1=send messages
immediately;
2 =first send empty UR and
wait for confirmation, then
send data filled URs;
3=first send empty UR and
wait for confirmation, wait
for enable UR from master
and then send data filled
URs]
0 Unsolicited messages reporting
behavior
Time synchronization
mode
0...2
[0=Never;
1=Periodic;
2=Startup]
2 See DNP 3.0 Remote Communication
Protocol for REF 54_ manual
(1MRS755260).
Baud rate 0...6
[0=300;
1=600;
2=1200;
3=2400;
4=4800;
5=9600;
6=19200]
5 Communication speed of DNP
protocol
Number of stop bits 1...2 1
Next character
timeout
0...65535 [ms]
1)
0
End of frame timeout
2....65535 [ms]
1)
10
Parity 0...2
[0=None;
1=Odd;
2=Even]
0
Silent interval 10...65535 [ms] 20
Collision detection
3)
Time slot width 10...65535 [ms] 10
Collision detection
3)
Number of time slots 1...255 8
Collision detection
3))
Collision detection
enabled
0...1
[0=Disabled;
1=Enabled]
0
Collision detection
3)
Protocol mapping
diagnostic parameter
DNP protocol mapping file
Protocol mapping
diagnostic parameter
Total entries counter
Protocol mapping
diagnostic parameter
Number of entries not in use
Protocol mapping
diagnostic parameter
Number of entries with invalid,
uncorrectable contents (INV)
Protocol mapping
diagnostic parameter
Number of entries with corrected
contents (COR)
Protocol mapping
diagnostic parameter
Number of entries referring to
nonexistent block (NBL)
Parameter Value Default Explanation
