Feeder Terminal
Technical Reference Manual, General
Table 5.2.1-12 General
Toolboxes CAP 501
CAP 505
LNT 505
Event recording all events are recorded in higher level syntax:
reason, time, date
the last 100 events are recorded
Data recording records operate values
Protection functions
Control functions
Condition monitoring functions
Measurement functions
Power quality functions
see Technical Descriptions of Functions, CD-ROM
Self-supervision RAM circuits
ROM circuits
Parameter memory circuits
CPU watchdog
Power supply
Digital I/O modules
HMI module
RTD/analog input module
Internal communication bus
A/D converters and analog multiplexers
Mechanical dimensions Width: 223.7 mm (1/2 of a 19” rack)
Height, frame: 265.9 mm (6U)
Height, box: 249.8 mm
Depth: 235 mm
For dimension drawings, refer to the RE_ 5__
Installation Manual
External display module: Width: 223.7 mm
Height: 265.9 mm
Depth: 74 mm
Weight of the unit ~8 kg
