IEC 61850 name AFL-Common SA name Description DPI value FUN INF InUse ASDU GI Coding LD0.SRGAPC1.Rs2.ctlVal - Reset SRGAPC1 flip-flop 2 10=Reset 11 102 1 20 0 1 LD0.SRGAPC1.Rs3.ctlVal - Reset SRGAPC1 flip-flop 3 10=Reset 11 103 1 20 0 1 LD0.SRGAPC1.Rs4.ctlVal - Reset SRGAPC1 flip-flop 4 10=Reset 11 104 1 20 0 1 LD0.SRGAPC1.Rs5.ctlVal - Reset SRGAPC1 flip-flop 5 10=Reset 11 105 1 20 0 1 LD0.SRGAPC1.Rs6.ctlVal - Reset SRGAPC1 flip-flop 6 10=Reset 11 106 1 20 0 1 LD0.SRGAPC1.Rs7.ctlVal - Reset SRGAPC1 flip-flop 7 10=Reset 11 107 1 20 0 1 LD0.SRGAPC1.Rs8.ctlVal - Reset SRGAPC1 flip-flop 8 10=Reset 11 108 1 20 0 1
Fuse failure protection
LD0.SEQRFUF1.Str.general SEQRFUF1.FUSEF_U General start 10=General start 22 84 1 2 1 1 LD0.SEQRFUF1.Str3Ph.general SEQRFUF1.FUSEF_3PH 3 phase start 10=3 phase start 22 94 1 2 1 1
Current circuit failure protection
CTRL.CCRDIF1.Alm.stVal CCRDIF1.FAIL Current circuit failure alarm 10 = Alarm 23 1 1 1 1 1 CTRL.CCRDIF1.Op.general CCRDIF1.ALARM Current circuit failure operate 10 = Operate 23 90 1 2 0 1
Frequency protection, 2 stages (ME02,ME03)
LD0.FRPTRC1.Str.general FRPFRQ1.START Stage 1 start 10 = Stage1 start 27 11 1 2 1 1 LD0.FRPTOF1.Op.general FRPFRQ1.OPR_OFRQ Operate 1 signal for overfrequency 10 = Stage1 overfrequency operate 27 12 1 2 0 1 LD0.FRPTUF1.Op.general FRPFRQ1.OPR_UFRQ
Operate 1 signal for underfrequency 10 = Stage1 underfrequency operate 27 13 1 2 0 1
LD0.FRPFRC1.Op.general FRPFRQ1.OPR_FRG
Operate 1 signal for frequency gradient
10= Stage1 frequency gradient operate 27 14 1 2 0 1
LD0.FRPTRC2.Str.general FRPFRQ2.START Stage 2 start 10 = Stage2 start 27 21 1 2 1 1 LD0.FRPTOF2.Op.general FRPFRQ2.OPR_OFRQ Operate 2 signal for overfrequency 10 = Stage2 overfrequency operate 27 22 1 2 0 1 LD0.FRPTUF2.Op.general FRPFRQ2.OPR_UFRQ
Operate 2 signal for underfrequency 10 = Stage2 underfrequency operate 27 23 1 2 0 1
LD0.FRPFRC2.Op.general FRPFRQ2.OPR_FRG
Operate 2 signal for frequency gradient
10 = Stage2 frequency gradient operate 27 24 1 2 0 1
Multipurpose analog protection functions (3 stages) (ME01,ME02)
LD0.MAPGAPC1.Str.general MAPGAPC1.START Stage 1 Start 10 = Stage1 start 27 151 1 1 1 1 LD0.MAPGAPC1.Op.general MAPGAPC1.OPERATE Stage 1 Operate 10 = Stage1 operate 27 152 1 1 0 1 LD0.MAPGAPC2.Str.general MAPGAPC2.START Stage 2 Start 10 = Stage2 start 27 153 1 1 1 1 LD0.MAPGAPC2.Op.general MAPGAPC2.OPERATE Stage 2 Operate 10 = Stage2 operate 27 154 1 1 0 1 LD0.MAPGAPC3.Str.general MAPGAPC3.START Stage 3 Start 10 = Stage3 start 27 155 1 1 1 1 LD0.MAPGAPC3.Op.general MAPGAPC3.OPERATE Stage 3 Operate 10 = Stage3 operate 27 156 1 1 0 1
XRGGIO130 Alarm/Warning (ME01,ME02)
LD0.XRGGIO130.Wrn.stVal XRGGIO130.WARNING XRGGIO130 Warning 10 = Warning 27 201 0 1 0 1 LD0.XRGGIO130.Alm.stVal XRGGIO130.ALARM XRGGIO130 Alarm 10 = Alarm 27 202 0 1 0 1
Phase undervoltage protection (1 stage)
LD0.PHPTUV1.Str.phsA - Start[.phsA] 10=PhsA start 41 64 0 2 1 1 LD0.PHPTUV1.Str.phsB - Start[.phsB] 10=PhsB start 41 65 0 2 1 1 LD0.PHPTUV1.Str.phsC - Start[.phsC] 10=PhsB start 41 66 0 2 1 1 LD0.PHPTUV1.Str.general PHPTUV1.START Start[.general] 10=Start general 41 84 1 2 1 1
Table continues on next page
1MRS756882 B Section 2
IEC 60870-5-103 data mappings
REM615 13
Point List Manual
