Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
14 RER620
Point List Manual
RDRE1.MemUsed.stVal 10112 DFR:MemUsed status Yes
SDARREC1.AutoRecSt.stVal 10113 79:AutoRecSt status Yes
SDARREC1.ShotPntr.stVal 10114 79:ShotPntr status Yes
SPHPTOV1.StrDur.mag.f 10115 59-1:StrDur magnitude Yes
SPHPTOV2.StrDur.mag.f 10116 59-2:StrDur magnitude Yes
SPHPTOV3.StrDur.mag.f 10117 59-3:StrDur magnitude Yes
SPHPTUV1.StrDur.mag.f 10118 27-1:StrDur magnitude Yes
SPHPTUV2.StrDur.mag.f 10119 27-2:StrDur magnitude Yes
SPHPTUV3.StrDur.mag.f 10120 27-3:StrDur magnitude Yes
SPSCBR1.AccAPwrPhA.mag.f 10121 52CM:AccAPwrPhA magnitude Yes
SPSCBR1.AccAPwrPhB.mag.f 10122 52CM:AccAPwrPhB magnitude Yes
SPSCBR1.AccAPwrPhC.mag.f 10123 52CM:AccAPwrPhC magnitude Yes
SPSCBR1.TmmsClsA.mag.f 10124 52CM:TmmsClsA magnitude Yes
SPSCBR1.TmmsClsB.mag.f 10125 52CM:TmmsClsB magnitude Yes
SPSCBR1.TmmsClsC.mag.f 10126 52CM:TmmsClsC magnitude Yes
SPSCBR1.TmmsOpnA.mag.f 10127 52CM:TmmsOpnA magnitude Yes
SPSCBR1.TmmsOpnB.mag.f 10128 52CM:TmmsOpnB magnitude Yes
SPSCBR1.TmmsOpnC.mag.f 10129 52CM:TmmsOpnC magnitude Yes
SPSCBR1.TmsSprCha.mag.f 10130 52CM:TmsSprCha magnitude Yes
XGGIO115.Swrev.mag.f 10149 XGGIO115:Swrev magnitude Yes
XNSPTOC1.StrDur.mag.f 10150 XNSPTOC1:StrDur magnitude Yes
XNSPTOC2.StrDur.mag.f 10151 XNSPTOC2:StrDur magnitude Yes
ZBAT1.AcInputVol.mag.f 10152 UPS:AcInputVol magnitude Yes
ZBAT1.Amp.mag.f 10153 UPS:Amp magnitude Yes
ZBAT1.AuxLoadI.mag.f 10154 UPS:AuxLoadI magnitude Yes
ZBAT1.BatTstDltV.mag.f 10155 UPS:BatTstDltV magnitude Yes
ZBAT1.BatTstVol.mag.f 10156 UPS:BatTstVol magnitude Yes
ZBAT1.RailVol12V.mag.f 10157 UPS:RailVol12V magnitude Yes
ZBAT1.Temp.mag.f 10158 UPS:Temp magnitude Yes
ZBAT1.UPSBldrVer.mag.f 10159 UPS:UPSBldrVer magnitude Yes
ZBAT1.UPSFwVer.mag.f 10160 UPS:UPSFwVer magnitude Yes
ZBAT1.UPSHwVer.mag.f 10161 UPS:UPSHwVer magnitude Yes
ZBAT1.Vol.mag.f 10162 UPS:Vol magnitude Yes
SECRSYN1.EnSt.stVal 10163 25:EnSt status Yes
FLTMSTA1.StrDur.mag.f 12000 Disabled FLTMSTA1:StrDur magnitude Yes
FLTMSTA1.MaxAmpsA.mag.f 12015 Disabled FLTMSTA1:MaxAmpsA magnitude Yes
FLTMSTA1.MaxAmpsB.mag.f 12016 Disabled FLTMSTA1:MaxAmpsB magnitude Yes
FLTMSTA1.MaxAmpsC.mag.f 12017 Disabled FLTMSTA1:MaxAmpsC magnitude Yes
FLTMSTA1.MaxAmpsN.mag.f 12018 Disabled FLTMSTA1:MaxAmpsN magnitude Yes
FLTMSTA1.AmpsA.mag.f 12019 Disabled FLTMSTA1:AmpsA magnitude Yes
FLTMSTA1.AmpsB.mag.f 12020 Disabled FLTMSTA1:AmpsB magnitude Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
