ABB RER620 - Page 21

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 15
Point List Manual
FLTMSTA1.AmpsC.mag.f 12021 Disabled FLTMSTA1:AmpsC magnitude Yes
FLTMSTA1.AmpsN.mag.f 12022 Disabled FLTMSTA1:AmpsN magnitude Yes
FLTMSTA1.AmpsNClc.mag.f 12023 Disabled FLTMSTA1:AmpsNClc magnitude Yes
FLTMSTA1.AmpsPsSeq.mag.f 12024 Disabled FLTMSTA1:AmpsPsSeq magnitude Yes
FLTMSTA1.AmpsNgSeq.mag.f 12025 Disabled FLTMSTA1:AmpsNgSeq magnitude Yes
FLTMSTA1.VoltsA.mag.f 12037 Disabled FLTMSTA1:VoltsA magnitude Yes
FLTMSTA1.VoltsB.mag.f 12038 Disabled FLTMSTA1:VoltsB magnitude Yes
FLTMSTA1.VoltsC.mag.f 12039 Disabled FLTMSTA1:VoltsC magnitude Yes
FLTMSTA1.VoltsAB.mag.f 12040 Disabled FLTMSTA1:VoltsAB magnitude Yes
FLTMSTA1.VoltsBC.mag.f 12041 Disabled FLTMSTA1:VoltsBC magnitude Yes
FLTMSTA1.VoltsCA.mag.f 12042 Disabled FLTMSTA1:VoltsCA magnitude Yes
FLTMSTA1.VoltsN.mag.f 12043 Disabled FLTMSTA1:VoltsN magnitude Yes
FLTMSTA1.VZroSeq.mag.f 12044 Disabled FLTMSTA1:VZroSeq magnitude Yes
FLTMSTA1.VPsSeq.mag.f 12045 Disabled FLTMSTA1:VPsSeq magnitude Yes
FLTMSTA1.VNgSeq.mag.f 12046 Disabled FLTMSTA1:VNgSeq magnitude Yes
FLTMSTA1.PDNS1MxRat.mag.f 12048 Disabled FLTMSTA1:PDNS1MxRat magnitude Yes
FLTMSTA1.DifNAngN.mag.f 12049 Disabled FLTMSTA1:DifNAngN magnitude Yes
FLTMSTA1.DifAAngBC.mag.f 12050 Disabled FLTMSTA1:DifAAngBC magnitude Yes
FLTMSTA1.DifBAngCA.mag.f 12051 Disabled FLTMSTA1:DifBAngCA magnitude Yes
FLTMSTA1.DifCAngAB.mag.f 12052 Disabled FLTMSTA1:DifCAngAB magnitude Yes
FLTMSTA1.Hz.mag.f 12053 Disabled FLTMSTA1:Hz magnitude Yes
FLTMSTA1.HzS.mag.f 12054 Disabled FLTMSTA1:HzS magnitude Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
