Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
16 RER620
Point List Manual
Table 3: Binary controls
No events 61850 Path IOA Disabled Description Multiplier Interrogation
* LLN0.LEDRs1.Oper.ctlVal 20000 LLN0:LEDRs1 control
* LLN0.LEDRs2.Oper.ctlVal 20001 LLN0:LEDRs2 control
* RDRE1.RcdTrg.Oper.ctlVal 20007 DFR:RcdTrg control
* RDRE1.MemClr.Oper.ctlVal 20008 DFR:MemClr control
* CMSTA1.RecRs.Oper.ctlVal 20009 CMSTA1:RecRs control
* LPHD1.RsDev.Oper.ctlVal 20013 LPHD1:RsDev control
* SCBCSWI1.Pos.Oper.ctlVal 21001 CB Control:Pos control
* SCBCSWI1.PosA.Oper.ctlVal 21002 CB Control:PosA control
* SCBCSWI1.PosB.Oper.ctlVal 21003 CB Control:PosB control
* SCBCSWI1.PosC.Oper.ctlVal 21004 CB Control:PosC control
* DNZSRDIR1.TstOutCmd.Oper.ctlVal 21100 32N:TstOutCmd control
* DPSRDIR1.TstOutCmd.Oper.ctlVal 21101 32P:TstOutCmd control
* LEDGGIO1.SPCSO1.Oper.ctlVal 21102 LEDGGIO1:SPCSO1 control
* LEDGGIO1.SPCSO10.Oper.ctlVal 21103 LEDGGIO1:SPCSO10 control
* LEDGGIO1.SPCSO11.Oper.ctlVal 21104 LEDGGIO1:SPCSO11 control
* LEDGGIO1.SPCSO2.Oper.ctlVal 21105 LEDGGIO1:SPCSO2 control
* LEDGGIO1.SPCSO3.Oper.ctlVal 21106 LEDGGIO1:SPCSO3 control
* LEDGGIO1.SPCSO4.Oper.ctlVal 21107 LEDGGIO1:SPCSO4 control
* LEDGGIO1.SPCSO5.Oper.ctlVal 21108 LEDGGIO1:SPCSO5 control
* LEDGGIO1.SPCSO6.Oper.ctlVal 21109 LEDGGIO1:SPCSO6 control
* LEDGGIO1.SPCSO7.Oper.ctlVal 21110 LEDGGIO1:SPCSO7 control
* LEDGGIO1.SPCSO8.Oper.ctlVal 21111 LEDGGIO1:SPCSO8 control
* LEDGGIO1.SPCSO9.Oper.ctlVal 21112 LEDGGIO1:SPCSO9 control
* SCCBRBCF1.TstOutCmd.Oper.ctlVal 21113 50BFC:TstOutCmd control
* SPCGGIO1.SPCSO1.Oper.ctlVal 21114 SPCGGIO1:SPCSO1 control
* SPCGGIO1.SPCSO10.Oper.ctlVal 21115 SPCGGIO1:SPCSO10 control
* SPCGGIO1.SPCSO11.Oper.ctlVal 21116 SPCGGIO1:SPCSO11 control
* SPCGGIO1.SPCSO12.Oper.ctlVal 21117 SPCGGIO1:SPCSO12 control
* SPCGGIO1.SPCSO13.Oper.ctlVal 21118 SPCGGIO1:SPCSO13 control
* SPCGGIO1.SPCSO14.Oper.ctlVal 21119 SPCGGIO1:SPCSO14 control
* SPCGGIO1.SPCSO15.Oper.ctlVal 21120 SPCGGIO1:SPCSO15 control
* SPCGGIO1.SPCSO16.Oper.ctlVal 21121 SPCGGIO1:SPCSO16 control
* SPCGGIO1.SPCSO2.Oper.ctlVal 21122 SPCGGIO1:SPCSO2 control
* SPCGGIO1.SPCSO3.Oper.ctlVal 21123 SPCGGIO1:SPCSO3 control
* SPCGGIO1.SPCSO4.Oper.ctlVal 21124 SPCGGIO1:SPCSO4 control
* SPCGGIO1.SPCSO5.Oper.ctlVal 21125 SPCGGIO1:SPCSO5 control
* SPCGGIO1.SPCSO6.Oper.ctlVal 21126 SPCGGIO1:SPCSO6 control
* SPCGGIO1.SPCSO7.Oper.ctlVal 21127 SPCGGIO1:SPCSO7 control
* SPCGGIO1.SPCSO8.Oper.ctlVal 21128 SPCGGIO1:SPCSO8 control
* SPCGGIO1.SPCSO9.Oper.ctlVal 21129 SPCGGIO1:SPCSO9 control
