ABB RER620 - Page 23

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 17
Point List Manual
* SPCGGIO2.SPCSO1.Oper.ctlVal 21130 SPCGGIO2:SPCSO1 control
* SPCGGIO2.SPCSO10.Oper.ctlVal 21131 SPCGGIO2:SPCSO10 control
* SPCGGIO2.SPCSO11.Oper.ctlVal 21132 SPCGGIO2:SPCSO11 control
* SPCGGIO2.SPCSO12.Oper.ctlVal 21133 SPCGGIO2:SPCSO12 control
* SPCGGIO2.SPCSO13.Oper.ctlVal 21134 SPCGGIO2:SPCSO13 control
* SPCGGIO2.SPCSO14.Oper.ctlVal 21135 SPCGGIO2:SPCSO14 control
* SPCGGIO2.SPCSO15.Oper.ctlVal 21136 SPCGGIO2:SPCSO15 control
* SPCGGIO2.SPCSO16.Oper.ctlVal 21137 SPCGGIO2:SPCSO16 control
* SPCGGIO2.SPCSO2.Oper.ctlVal 21138 SPCGGIO2:SPCSO2 control
* SPCGGIO2.SPCSO3.Oper.ctlVal 21139 SPCGGIO2:SPCSO3 control
* SPCGGIO2.SPCSO4.Oper.ctlVal 21140 SPCGGIO2:SPCSO4 control
* SPCGGIO2.SPCSO5.Oper.ctlVal 21141 SPCGGIO2:SPCSO5 control
* SPCGGIO2.SPCSO6.Oper.ctlVal 21142 SPCGGIO2:SPCSO6 control
* SPCGGIO2.SPCSO7.Oper.ctlVal 21143 SPCGGIO2:SPCSO7 control
* SPCGGIO2.SPCSO8.Oper.ctlVal 21144 SPCGGIO2:SPCSO8 control
* SPCGGIO2.SPCSO9.Oper.ctlVal 21145 SPCGGIO2:SPCSO9 control
* SPHPTOV1.TstOutCmd.Oper.ctlVal 21146 59-1:TstOutCmd control
* SPHPTOV2.TstOutCmd.Oper.ctlVal 21147 59-2:TstOutCmd control
* SPHPTOV3.TstOutCmd.Oper.ctlVal 21148 59-3:TstOutCmd control
* SPHPTUV1.TstOutCmd.Oper.ctlVal 21149 27-1:TstOutCmd control
* SPHPTUV2.TstOutCmd.Oper.ctlVal 21150 27-2:TstOutCmd control
* SPHPTUV3.TstOutCmd.Oper.ctlVal 21151 27-3:TstOutCmd control
* SPSCBR1.RsAccAPwr.Oper.ctlVal 21152 52CM:RsAccAPwr control
* SPSCBR1.RsCBWear.Oper.ctlVal 21153 52CM:RsCBWear control
* SPSCBR1.RsSprChaTm.Oper.ctlVal 21154 52CM:RsSprChaTm control
* SPSCBR1.RsTrvTm.Oper.ctlVal 21155 52CM:RsTrvTm control
* SPSCBR1.TstOutCmd.Oper.ctlVal 21156 52CM:TstOutCmd control
* SRGAPC1.Rs1.Oper.ctlVal 21157 SRGAPC1:Rs1 control
* SRGAPC1.Rs2.Oper.ctlVal 21158 SRGAPC1:Rs2 control
* SRGAPC1.Rs3.Oper.ctlVal 21159 SRGAPC1:Rs3 control
* SRGAPC1.Rs4.Oper.ctlVal 21160 SRGAPC1:Rs4 control
* SRGAPC1.Rs5.Oper.ctlVal 21161 SRGAPC1:Rs5 control
* SRGAPC1.Rs6.Oper.ctlVal 21162 SRGAPC1:Rs6 control
* SRGAPC1.Rs7.Oper.ctlVal 21163 SRGAPC1:Rs7 control
* SRGAPC1.Rs8.Oper.ctlVal 21164 SRGAPC1:Rs8 control
* SRGAPC2.Rs1.Oper.ctlVal 21165 SRGAPC2:Rs1 control
* SRGAPC2.Rs2.Oper.ctlVal 21166 SRGAPC2:Rs2 control
* SRGAPC2.Rs3.Oper.ctlVal 21167 SRGAPC2:Rs3 control
* SRGAPC2.Rs4.Oper.ctlVal 21168 SRGAPC2:Rs4 control
* SRGAPC2.Rs5.Oper.ctlVal 21169 SRGAPC2:Rs5 control
* SRGAPC2.Rs6.Oper.ctlVal 21170 SRGAPC2:Rs6 control
No events 61850 Path IOA Disabled Description Multiplier Interrogation
