Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
18 RER620
Point List Manual
* SRGAPC2.Rs7.Oper.ctlVal 21171 SRGAPC2:Rs7 control
* SRGAPC2.Rs8.Oper.ctlVal 21172 SRGAPC2:Rs8 control
* XGGIO100.SPCSO1.Oper.ctlVal 21173 XGGIO100:SPCSO1 control
* XGGIO100.SPCSO2.Oper.ctlVal 21174 XGGIO100:SPCSO2 control
* XGGIO100.SPCSO3.Oper.ctlVal 21175 XGGIO100:SPCSO3 control
* XGGIO100.SPCSO4.Oper.ctlVal 21176 XGGIO100:SPCSO4 control
* XGGIO100.SPCSO5.Oper.ctlVal 21177 XGGIO100:SPCSO5 control
* XGGIO100.SPCSO6.Oper.ctlVal 21178 XGGIO100:SPCSO6 control
* XGGIO105.SPCSO1.Oper.ctlVal 21179 XGGIO105:SPCSO1 control
* XGGIO105.SPCSO2.Oper.ctlVal 21180 XGGIO105:SPCSO2 control
* XGGIO105.SPCSO3.Oper.ctlVal 21181 XGGIO105:SPCSO3 control
* XGGIO105.SPCSO4.Oper.ctlVal 21182 XGGIO105:SPCSO4 control
* XGGIO110.SPCSO1.Oper.ctlVal 21183 XGGIO110:SPCSO1 control
* XGGIO110.SPCSO2.Oper.ctlVal 21184 XGGIO110:SPCSO2 control
* XGGIO110.SPCSO3.Oper.ctlVal 21185 XGGIO110:SPCSO3 control
* XGGIO110.SPCSO4.Oper.ctlVal 21186 XGGIO110:SPCSO4 control
* XNSPTOC1.TstOutCmd.Oper.ctlVal 21187 XNSPTOC1:TstOutCmd control
* XNSPTOC2.TstOutCmd.Oper.ctlVal 21188 XNSPTOC2:TstOutCmd control
* ZBAT1.BatTest.Oper.ctlVal 21189 UPS:BatTest control
* ZBAT1.ResetUps.Oper.ctlVal 21190 UPS:ResetUps control
* ZBAT1.SetBootLdr.Oper.ctlVal 21191 UPS:SetBootLdr control
* ZBAT1.TestComm.Oper.ctlVal 21192 UPS:TestComm control
I5CGGIO1.ActSG.stVal 40000 Active setting group Yes
I5CGGIO1.ActSG.stVal 40001 Setting group 1 Yes
I5CGGIO1.ActSG.stVal 40002 Setting group 2 Yes
I5CGGIO1.ActSG.stVal 40003 Setting group 3 Yes
I5CGGIO1.ActSG.stVal 40004 Setting group 4 Yes
I5CGGIO1.ActSG.stVal 40005 Setting group 5 Yes
I5CGGIO1.ActSG.stVal 40006 Setting group 6 Yes
* I5CGGIO1.ActSG1.Oper.ctlVal 41001 Activate setting group 1
* I5CGGIO1.ActSG2.Oper.ctlVal 41002 Activate setting group 2
* I5CGGIO1.ActSG3.Oper.ctlVal 41003 Activate setting group 3
* I5CGGIO1.ActSG4.Oper.ctlVal 41004 Activate setting group 4
* I5CGGIO1.ActSG5.Oper.ctlVal 41005 Activate setting group 5
* I5CGGIO1.ActSG6.Oper.ctlVal 41006 Activate setting group 6
No events 61850 Path IOA Disabled Description Multiplier Interrogation
