Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
20 RER620
Point List Manual
FKEYGGIO1.Ind9.stVal 108 FKEYGGIO1:Ind9 status Yes
FKEYGGIO1.Ind10.stVal 109 FKEYGGIO1:Ind10 status Yes
FKEYGGIO1.Ind11.stVal 110 FKEYGGIO1:Ind11 status Yes
FKEYGGIO1.Ind12.stVal 111 FKEYGGIO1:Ind12 status Yes
FKEYGGIO1.Ind13.stVal 112 FKEYGGIO1:Ind13 status Yes
FKEYGGIO1.Ind14.stVal 113 FKEYGGIO1:Ind14 status Yes
FKEYGGIO1.Ind15.stVal 114 FKEYGGIO1:Ind15 status Yes
FKEYGGIO1.Ind16.stVal 115 FKEYGGIO1:Ind16 status Yes
DRFLO1.FltLoop.stVal 120 FLO:FltLoop status Yes
PTGAPC1.In1.stVal 130 PTGAPC1:In1 status Yes
PTGAPC1.In2.stVal 131 PTGAPC1:In2 status Yes
PTGAPC1.In3.stVal 132 PTGAPC1:In3 status Yes
PTGAPC1.In4.stVal 133 PTGAPC1:In4 status Yes
PTGAPC1.In5.stVal 134 PTGAPC1:In5 status Yes
PTGAPC1.In6.stVal 135 PTGAPC1:In6 status Yes
PTGAPC1.In7.stVal 136 PTGAPC1:In7 status Yes
PTGAPC1.In8.stVal 137 PTGAPC1:In8 status Yes
PTGAPC1.Q1.stVal 138 PTGAPC1:Q1 status Yes
PTGAPC1.Q2.stVal 139 PTGAPC1:Q2 status Yes
PTGAPC1.Q3.stVal 140 PTGAPC1:Q3 status Yes
PTGAPC1.Q4.stVal 141 PTGAPC1:Q4 status Yes
PTGAPC1.Q5.stVal 142 PTGAPC1:Q5 status Yes
PTGAPC1.Q6.stVal 143 PTGAPC1:Q6 status Yes
PTGAPC1.Q7.stVal 144 PTGAPC1:Q7 status Yes
PTGAPC1.Q8.stVal 145 PTGAPC1:Q8 status Yes
SRGAPC1.Q1.stVal 150 SRGAPC1:Q1 status Yes
SRGAPC1.Q2.stVal 151 SRGAPC1:Q2 status Yes
SRGAPC1.Q3.stVal 152 SRGAPC1:Q3 status Yes
SRGAPC1.Q4.stVal 153 SRGAPC1:Q4 status Yes
SRGAPC1.Q5.stVal 154 SRGAPC1:Q5 status Yes
SRGAPC1.Q6.stVal 155 SRGAPC1:Q6 status Yes
SRGAPC1.Q7.stVal 156 SRGAPC1:Q7 status Yes
SRGAPC1.Q8.stVal 157 SRGAPC1:Q8 status Yes
SRGAPC1.Set1.stVal 158 SRGAPC1:Set1 status Yes
SRGAPC1.Set2.stVal 159 SRGAPC1:Set2 status Yes
SRGAPC1.Set3.stVal 160 SRGAPC1:Set3 status Yes
SRGAPC1.Set4.stVal 161 SRGAPC1:Set4 status Yes
SRGAPC1.Set5.stVal 162 SRGAPC1:Set5 status Yes
SRGAPC1.Set6.stVal 163 SRGAPC1:Set6 status Yes
SRGAPC1.Set7.stVal 164 SRGAPC1:Set7 status Yes
SRGAPC1.Set8.stVal 165 SRGAPC1:Set8 status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
