ABB RER620 - Page 27

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 21
Point List Manual
TOFGAPC1.In1.stVal 170 TOFGAPC1:In1 status Yes
TOFGAPC1.In2.stVal 171 TOFGAPC1:In2 status Yes
TOFGAPC1.In3.stVal 172 TOFGAPC1:In3 status Yes
TOFGAPC1.In4.stVal 173 TOFGAPC1:In4 status Yes
TOFGAPC1.In5.stVal 174 TOFGAPC1:In5 status Yes
TOFGAPC1.In6.stVal 175 TOFGAPC1:In6 status Yes
TOFGAPC1.In7.stVal 176 TOFGAPC1:In7 status Yes
TOFGAPC1.In8.stVal 177 TOFGAPC1:In8 status Yes
TOFGAPC1.Q1.stVal 178 TOFGAPC1:Q1 status Yes
TOFGAPC1.Q2.stVal 179 TOFGAPC1:Q2 status Yes
TOFGAPC1.Q3.stVal 180 TOFGAPC1:Q3 status Yes
TOFGAPC1.Q4.stVal 181 TOFGAPC1:Q4 status Yes
TOFGAPC1.Q5.stVal 182 TOFGAPC1:Q5 status Yes
TOFGAPC1.Q6.stVal 183 TOFGAPC1:Q6 status Yes
TOFGAPC1.Q7.stVal 184 TOFGAPC1:Q7 status Yes
TOFGAPC1.Q8.stVal 185 TOFGAPC1:Q8 status Yes
TONGAPC1.In1.stVal 190 TONGAPC1:In1 status Yes
TONGAPC1.In2.stVal 191 TONGAPC1:In2 status Yes
TONGAPC1.In3.stVal 192 TONGAPC1:In3 status Yes
TONGAPC1.In4.stVal 193 TONGAPC1:In4 status Yes
TONGAPC1.In5.stVal 194 TONGAPC1:In5 status Yes
TONGAPC1.In6.stVal 195 TONGAPC1:In6 status Yes
TONGAPC1.In7.stVal 196 TONGAPC1:In7 status Yes
TONGAPC1.In8.stVal 197 TONGAPC1:In8 status Yes
TONGAPC1.Q1.stVal 198 TONGAPC1:Q1 status Yes
TONGAPC1.Q2.stVal 199 TONGAPC1:Q2 status Yes
TONGAPC1.Q3.stVal 200 TONGAPC1:Q3 status Yes
TONGAPC1.Q4.stVal 201 TONGAPC1:Q4 status Yes
TONGAPC1.Q5.stVal 202 TONGAPC1:Q5 status Yes
TONGAPC1.Q6.stVal 203 TONGAPC1:Q6 status Yes
TONGAPC1.Q7.stVal 204 TONGAPC1:Q7 status Yes
TONGAPC1.Q8.stVal 205 TONGAPC1:Q8 status Yes
ZBAT1.ACLoss.stVal 210 UPS:ACLoss status Yes
ZBAT1.Auxinfo.stVal 211 UPS:Auxinfo status Yes
ZBAT1.AuxStat.stVal 212 UPS:AuxStat status Yes
ZBAT1.AuxVol.stVal 213 UPS:AuxVol status Yes
ZBAT1.BatConn.stVal 214 UPS:BatConn status Yes
ZBAT1.BatTstStat.stVal 216 UPS:BatTstStat status Yes
ZBAT1.BstVolVal.stVal 217 UPS:BstVolVal status Yes
ZBAT1.RelaySt.stVal 218 UPS:RelaySt status Yes
ZBAT1.RlVol60V.stVal 219 UPS:RlVol60V status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
