Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
22 RER620
Point List Manual
ZBAT1.SwConnSt.stVal 220 UPS:SwConnSt status Yes
ZBAT1.UpsAlmStat.stVal 221 UPS:UpsAlmStat status Yes
ZBAT1.UpsTimeDay.stVal 222 UPS:UpsTimeDay status Yes
ZBAT1.UpsTimeHr.stVal 223 UPS:UpsTimeHr status Yes
ZBAT1.UpsTimeMin.stVal 224 UPS:UpsTimeMin status Yes
ZBAT1.UpsTimeSec.stVal 225 UPS:UpsTimeSec status Yes
MVGAPC1.Q1.stVal 230 MVGAPC1:Open Yes
MVGAPC1.Q2.stVal 231 MVGAPC1:Closed Yes
MVGAPC1.Q3.stVal 232 MVGAPC1:Phase A Open Yes
MVGAPC1.Q4.stVal 233 MVGAPC1:Phase A Closed Yes
MVGAPC1.Q5.stVal 234 MVGAPC1:Phase B Open Yes
MVGAPC1.Q6.stVal 235 MVGAPC1:Phase B Closed Yes
MVGAPC1.Q7.stVal 236 MVGAPC1:Phase C Open Yes
MVGAPC1.Q8.stVal 237 MVGAPC1:Phase C Closed Yes
MVGAPC2.Q1.stVal 240 MVGAPC2:Q1 status Yes
MVGAPC2.Q2.stVal 241 MVGAPC2:Q2 status Yes
MVGAPC2.Q3.stVal 242 MVGAPC2:Q3 status Yes
MVGAPC2.Q4.stVal 243 MVGAPC2:Q4 status Yes
MVGAPC2.Q5.stVal 244 MVGAPC2:Q5 status Yes
MVGAPC2.Q6.stVal 245 MVGAPC2:Q6 status Yes
MVGAPC2.Q7.stVal 246 MVGAPC2:Q7 status Yes
MVGAPC2.Q8.stVal 247 MVGAPC2:Q8 status Yes
PTGAPC2.In1.stVal 250 PTGAPC2:In1 status Yes
PTGAPC2.In2.stVal 251 PTGAPC2:In2 status Yes
PTGAPC2.In3.stVal 252 PTGAPC2:In3 status Yes
PTGAPC2.In4.stVal 253 PTGAPC2:In4 status Yes
PTGAPC2.In5.stVal 254 PTGAPC2:In5 status Yes
PTGAPC2.In6.stVal 255 PTGAPC2:In6 status Yes
PTGAPC2.In7.stVal 256 PTGAPC2:In7 status Yes
PTGAPC2.In8.stVal 257 PTGAPC2:In8 status Yes
PTGAPC2.Q1.stVal 258 PTGAPC2:Q1 status Yes
PTGAPC2.Q2.stVal 259 PTGAPC2:Q2 status Yes
PTGAPC2.Q3.stVal 260 PTGAPC2:Q3 status Yes
PTGAPC2.Q4.stVal 261 PTGAPC2:Q4 status Yes
PTGAPC2.Q5.stVal 262 PTGAPC2:Q5 status Yes
PTGAPC2.Q6.stVal 263 PTGAPC2:Q6 status Yes
PTGAPC2.Q7.stVal 264 PTGAPC2:Q7 status Yes
PTGAPC2.Q8.stVal 265 PTGAPC2:Q8 status Yes
SRGAPC2.Q1.stVal 270 SRGAPC2:Q1 status Yes
SRGAPC2.Q2.stVal 271 SRGAPC2:Q2 status Yes
SRGAPC2.Q3.stVal 272 SRGAPC2:Q3 status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
