1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 23
Point List Manual
SRGAPC2.Q4.stVal 273 SRGAPC2:Q4 status Yes
SRGAPC2.Q5.stVal 274 SRGAPC2:Q5 status Yes
SRGAPC2.Q6.stVal 275 SRGAPC2:Q6 status Yes
SRGAPC2.Q7.stVal 276 SRGAPC2:Q7 status Yes
SRGAPC2.Q8.stVal 277 SRGAPC2:Q8 status Yes
SRGAPC2.Set1.stVal 278 SRGAPC2:Set1 status Yes
SRGAPC2.Set2.stVal 279 SRGAPC2:Set2 status Yes
SRGAPC2.Set3.stVal 280 SRGAPC2:Set3 status Yes
SRGAPC2.Set4.stVal 281 SRGAPC2:Set4 status Yes
SRGAPC2.Set5.stVal 282 SRGAPC2:Set5 status Yes
SRGAPC2.Set6.stVal 283 SRGAPC2:Set6 status Yes
SRGAPC2.Set7.stVal 284 SRGAPC2:Set7 status Yes
SRGAPC2.Set8.stVal 285 SRGAPC2:Set8 status Yes
TOFGAPC2.In1.stVal 290 TOFGAPC2:In1 status Yes
TOFGAPC2.In2.stVal 291 TOFGAPC2:In2 status Yes
TOFGAPC2.In3.stVal 292 TOFGAPC2:In3 status Yes
TOFGAPC2.In4.stVal 293 TOFGAPC2:In4 status Yes
TOFGAPC2.In5.stVal 294 TOFGAPC2:In5 status Yes
TOFGAPC2.In6.stVal 295 TOFGAPC2:In6 status Yes
TOFGAPC2.In7.stVal 296 TOFGAPC2:In7 status Yes
TOFGAPC2.In8.stVal 297 TOFGAPC2:In8 status Yes
TOFGAPC2.Q1.stVal 298 TOFGAPC2:Q1 status Yes
TOFGAPC2.Q2.stVal 299 TOFGAPC2:Q2 status Yes
TOFGAPC2.Q3.stVal 300 TOFGAPC2:Q3 status Yes
TOFGAPC2.Q4.stVal 301 TOFGAPC2:Q4 status Yes
TOFGAPC2.Q5.stVal 302 TOFGAPC2:Q5 status Yes
TOFGAPC2.Q6.stVal 303 TOFGAPC2:Q6 status Yes
TOFGAPC2.Q7.stVal 304 TOFGAPC2:Q7 status Yes
TONGAPC2.In1.stVal 310 TONGAPC2:In1 status Yes
TONGAPC2.In2.stVal 311 TONGAPC2:In2 status Yes
TONGAPC2.In3.stVal 312 TONGAPC2:In3 status Yes
TONGAPC2.In4.stVal 313 TONGAPC2:In4 status Yes
TONGAPC2.In5.stVal 314 TONGAPC2:In5 status Yes
TONGAPC2.In6.stVal 315 TONGAPC2:In6 status Yes
TONGAPC2.In7.stVal 316 TONGAPC2:In7 status Yes
TONGAPC2.In8.stVal 317 TONGAPC2:In8 status Yes
TONGAPC2.Q1.stVal 318 TONGAPC2:Q1 status Yes
TONGAPC2.Q2.stVal 319 TONGAPC2:Q2 status Yes
TONGAPC2.Q3.stVal 320 TONGAPC2:Q3 status Yes
TONGAPC2.Q4.stVal 321 TONGAPC2:Q4 status Yes
TONGAPC2.Q5.stVal 322 TONGAPC2:Q5 status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
