IEC 60870-5-101/104 data mappings
24 RER620
Point List Manual
TONGAPC2.Q6.stVal 323 TONGAPC2:Q6 status Yes
TONGAPC2.Q7.stVal 324 TONGAPC2:Q7 status Yes
TONGAPC2.Q8.stVal 325 TONGAPC2:Q8 status Yes
DLCM1.BrkSt.stVal 816 LCM:BrkSt status Yes
DLCM1.LCMClose.general 817 LCM:Close general Yes
DLCM1.LCMTrip.general 818 LCM:Trip general Yes
DLCM1.RstIn.stVal 820 LCM:RstIn status Yes
DLCM1.RstOut.stVal 821 LCM:RstOut status Yes
DLCM1.S1Status.stVal 822 LCM:S1Status status Yes
DLCM1.S2Status.stVal 823 LCM:S2Status status Yes
DLCM1.SetGrpSel.stVal 824 LCM:SetGrpSel status Yes
DLCM1.Src1Enable.stVal 825 LCM:Src1Enable status Yes
DLCM1.Src1EnOut.stVal 826 LCM:Src1EnOut status Yes
DLCM1.Src2Enable.stVal 827 LCM:Src2Enable status Yes
DLCM1.Src2EnOut.stVal 828 LCM:Src2EnOut status Yes
DLCM1.SWOTF.stVal 829 LCM:SWOTF status Yes
DNZSRDIR1.Dir.general 830 32N:general
DNZSRDIR1.InRcaCtl.stVal 831 32N:InRcaCtl status
DPSRDIR1.Dir.general 856 32P:general Yes
DRFLO1.Tr.general 857 FLO:general Yes
EFLPTOC3.Op.general 868 50SEF:general trip
EFLPTOC3.Str.general 869 50SEF:general pickup Yes
FRPTOF1.Op.general 883 FRPTOF1:general trip
FRPTOF2.Op.general 884 FRPTOF2:general trip
FRPTRC1.Str.general 889 Freq1:general pickup Yes
FRPTRC2.Str.general 890 Freq2:general pickup Yes
FRPTUF1.Op.general 895 FRPTUF1:general trip
FRPTUF2.Op.general 896 FRPTUF2:general trip
INRPHAR1.Str.general 903 INRPHAR1:general pickup Yes
INRPHAR1.Str.phsA 904 INRPHAR1:phase A pickup Yes
INRPHAR1.Str.phsB 905 INRPHAR1:phase B pickup Yes
INRPHAR1.Str.phsC 906 INRPHAR1:phase C pickup Yes
LSHDPTRC1.Op.general 916 LSHDPTRC1:general trip
LSHDPTRC1.RestLodOp.general 917 LSHDPTRC1:general
LSHDPTRC1.RestLodStr.general 918 LSHDPTRC1:general Yes
LSHDPTRC1.Str.general 919 LSHDPTRC1:general pickup Yes
LSHDPTRC2.Op.general 920 LSHDPTRC2:general trip
LSHDPTRC2.RestLodOp.general 921 LSHDPTRC2:general
LSHDPTRC2.RestLodStr.general 922 LSHDPTRC2:general Yes
LSHDPTRC2.Str.general 923 LSHDPTRC2:general pickup Yes
MVGAPC2.Op.general 955 MVGAPC2:general trip
No events 61850 Path IOA Disabled Description Multiplier Interrogation
