1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 25
Point List Manual
MVGAPC2.Str.general 956 MVGAPC2:general pickup Yes
NSPTOV1.Op.general 965 47-1:general trip
NSPTOV1.Str.general 966 47-1:general pickup Yes
NSPTOV2.Op.general 967 47-2:general trip
NSPTOV2.Str.general 968 47-2:general pickup Yes
PDNSPTOC1.Op.general 973 PDNSPTOC1:general trip
PDNSPTOC1.Str.general 974 PDNSPTOC1:general pickup Yes
PHIZ1.Op.general 1004 HIZ:general trip
PHIZ1.Str.general 1005 HIZ:general pickup Yes
PSPTOV1.Op.general 1069 59PS-1:general trip
PSPTOV1.Str.general 1070 59PS-1:general pickup Yes
PSPTOV2.Op.general 1071 59PS-2:general trip
PSPTOV2.Str.general 1072 59PS-2:general pickup Yes
PTGAPC1.Op.general 1081 PTGAPC1:general trip
PTGAPC1.Str.general 1082 PTGAPC1:general pickup Yes
PTGAPC2.Op.general 1083 PTGAPC2:general trip
PTGAPC2.Str.general 1084 PTGAPC2:general pickup Yes
ROVPTOV1.Op.general 1085 59N-1:general trip
ROVPTOV1.Str.general 1086 59N-1:general pickup Yes
ROVPTOV2.Op.general 1087 59N-2:general trip
ROVPTOV2.Str.general 1088 59N-2:general pickup Yes
SCCBRBCF1.InCBFlt.stVal 1091 50BFC:InCBFlt status Yes
SCCBRBCF1.InPosClsA.stVal 1092 50BFC:InPosClsA status Yes
SCCBRBCF1.InPosClsB.stVal 1093 50BFC:InPosClsB status Yes
SCCBRBCF1.InPosClsC.stVal 1094 50BFC:InPosClsC status Yes
SCCBRBCF1.InStr.stVal 1095 50BFC:InStr status Yes
SCCBRBCF1.InStrA.stVal 1096 50BFC:InStrA status Yes
SCCBRBCF1.InStrB.stVal 1097 50BFC:InStrB status Yes
SCCBRBCF1.InStrC.stVal 1098 50BFC:InStrC status Yes
SCCBRBCF1.OpCls.general 1099 50BFC:general Yes
SCCBRBRF1.InCBFlt.stVal 1100 50BFT:InCBFlt status Yes
SCCBRBRF1.InPosClsA.stVal 1101 50BFT:InPosClsA status Yes
SCCBRBRF1.InPosClsB.stVal 1102 50BFT:InPosClsB status Yes
SCCBRBRF1.InPosClsC.stVal 1103 50BFT:InPosClsC status Yes
SCCBRBRF1.InStr.stVal 1104 50BFT:InStr status Yes
SCCBRBRF1.InStrA.stVal 1105 50BFT:InStrA status Yes
SCCBRBRF1.InStrB.stVal 1106 50BFT:InStrB status Yes
SCCBRBRF1.InStrC.stVal 1107 50BFT:InStrC status Yes
SCCBRBRF1.OpEx.general 1108 50BFT:general Yes
SCCBRBRF1.OpIn.general 1109 50BFT:general Yes
SCCBRBRF1.Str.general 1110 50BFT:general pickup Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
