IEC 60870-5-101/104 data mappings
26 RER620
Point List Manual
SDARREC1.Op.phsA 1111 79:phase A trip
SDARREC1.Op.phsB 1112 79:phase B trip
SDARREC1.Op.phsC 1113 79:phase C trip
SDARREC1.OpOpn.phsA 1114 79:phase A Yes
SDARREC1.OpOpn.phsB 1115 79:phase B Yes
SDARREC1.OpOpn.phsC 1116 79:phase C Yes
SDPHLPTOC1.Op.general 1117 67/51P-1:general trip
SDPHLPTOC1.Op.phsA 1118 67/51P-1:phase A trip
SDPHLPTOC1.Op.phsB 1119 67/51P-1:phase B trip
SDPHLPTOC1.Op.phsC 1120 67/51P-1:phase C trip
SDPHLPTOC1.Str.general 1121 67/51P-1:general pickup Yes
SDPHLPTOC1.Str.phsA 1122 67/51P-1:phase A pickup Yes
SDPHLPTOC1.Str.phsB 1123 67/51P-1:phase B pickup Yes
SDPHLPTOC1.Str.phsC 1124 67/51P-1:phase C pickup Yes
SDPHLPTOC2.Op.general 1125 67/51P-2:general trip
SDPHLPTOC2.Op.phsA 1126 67/51P-2:phase A trip
SDPHLPTOC2.Op.phsB 1127 67/51P-2:phase B trip
SDPHLPTOC2.Op.phsC 1128 67/51P-2:phase C trip
SDPHLPTOC2.Str.general 1129 67/51P-2:general pickup Yes
SDPHLPTOC2.Str.phsA 1130 67/51P-2:phase A pickup Yes
SDPHLPTOC2.Str.phsB 1131 67/51P-2:phase B pickup Yes
SDPHLPTOC2.Str.phsC 1132 67/51P-2:phase C pickup Yes
SECRSYN1.FailCmd.stVal 1134 25:FailCmd status Yes
SECRSYN1.FailSyn.stVal 1135 25:FailSyn status Yes
SECRSYN1.SynPrg.stVal 1136 25:SynPrg status Yes
SEQRFUF1.Str.general 1137 60:general pickup Yes
SEQRFUF1.Str3Ph.general 1138 60:general Yes
SPHHPTOC1.Op.general 1139 SPHHPTOC1:general trip
SPHHPTOC1.Op.phsA 1140 SPHHPTOC1:phase A trip
SPHHPTOC1.Op.phsB 1141 SPHHPTOC1:phase B trip
SPHHPTOC1.Op.phsC 1142 SPHHPTOC1:phase C trip
SPHHPTOC1.Str.general 1143 SPHHPTOC1:general pickup Yes
SPHHPTOC1.Str.phsA 1144 SPHHPTOC1:phase A pickup Yes
SPHHPTOC1.Str.phsB 1145 SPHHPTOC1:phase B pickup Yes
SPHHPTOC1.Str.phsC 1146 SPHHPTOC1:phase C pickup Yes
SPHIPTOC1.Op.general 1155 SPHIPTOC1:general trip
SPHIPTOC1.Op.phsA 1156 SPHIPTOC1:phase A trip
SPHIPTOC1.Op.phsB 1157 SPHIPTOC1:phase B trip
SPHIPTOC1.Op.phsC 1158 SPHIPTOC1:phase C trip
SPHIPTOC1.Str.general 1159 SPHIPTOC1:general pickup Yes
SPHIPTOC1.Str.phsA 1160 SPHIPTOC1:phase A pickup Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
