1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 27
Point List Manual
SPHIPTOC1.Str.phsB 1161 SPHIPTOC1:phase B pickup Yes
SPHIPTOC1.Str.phsC 1162 SPHIPTOC1:phase C pickup Yes
SPHLPTOC1.Op.general 1163 51P:general trip
SPHLPTOC1.Op.phsA 1164 51P:phase A trip
SPHLPTOC1.Op.phsB 1165 51P:phase B trip
SPHLPTOC1.Op.phsC 1166 51P:phase C trip
SPHLPTOC1.Str.general 1167 51P:general pickup Yes
SPHLPTOC1.Str.phsA 1168 51P:phase A pickup Yes
SPHLPTOC1.Str.phsB 1169 51P:phase B pickup Yes
SPHLPTOC1.Str.phsC 1170 51P:phase C pickup Yes
SPHLPTOC2.Op.general 1171 50P-1:general trip
SPHLPTOC2.Op.phsA 1172 50P-1:phase A trip
SPHLPTOC2.Op.phsB 1173 50P-1:phase B trip
SPHLPTOC2.Op.phsC 1174 50P-1:phase C trip
SPHLPTOC2.Str.general 1175 50P-1:general pickup Yes
SPHLPTOC2.Str.phsA 1176 50P-1:phase A pickup Yes
SPHLPTOC2.Str.phsB 1177 50P-1:phase B pickup Yes
SPHLPTOC2.Str.phsC 1178 50P-1:phase C pickup Yes
SPHPTOV1.Op.general 1179 59-1:general trip
SPHPTOV1.Str.general 1180 59-1:general pickup Yes
SPHPTOV2.Op.general 1181 59-2:general trip
SPHPTOV2.Str.general 1182 59-2:general pickup Yes
SPHPTOV3.Op.general 1183 59-3:general trip
SPHPTOV3.Str.general 1184 59-3:general pickup Yes
SPHPTUV1.Op.general 1185 27-1:general trip
SPHPTUV1.Str.general 1186 27-1:general pickup Yes
SPHPTUV2.Op.general 1187 27-2:general trip
SPHPTUV2.Str.general 1188 27-2:general pickup Yes
SPHPTUV3.Op.general 1189 27-3:general trip
SPHPTUV3.Str.general 1190 27-3:general pickup Yes
SRGAPC1.Op.general 1191 SRGAPC1:general trip
SRGAPC1.Str.general 1192 SRGAPC1:general pickup Yes
SRGAPC2.Op.general 1193 SRGAPC2:general trip
SRGAPC2.Str.general 1194 SRGAPC2:general pickup Yes
TOFGAPC1.Op.general 1206 TOFGAPC1:general trip
TOFGAPC1.Str.general 1207 TOFGAPC1:general pickup Yes
TOFGAPC2.Op.general 1208 TOFGAPC2:general trip
TOFGAPC2.Str.general 1209 TOFGAPC2:general pickup Yes
TONGAPC1.Op.general 1210 TONGAPC1:general trip
TONGAPC1.Str.general 1211 TONGAPC1:general pickup Yes
TONGAPC2.Op.general 1212 TONGAPC2:general trip
No events 61850 Path IOA Disabled Description Multiplier Interrogation
