ABB RER620 - Page 35

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 29
Point List Manual
SDARREC1.ActRec.stVal 2860 79:ActRec status Yes
SDARREC1.PrgDsr.stVal 2861 79:PrgDsr status Yes
SDARREC1.PrgCutOut.stVal 2862 79:PrgCutOut status Yes
SDARREC1.FrqOpAlm.stVal 2863 79:FrqOpAlm status Yes
SDARREC1.CBManCls.stVal 2864 79:CBManCls status Yes
SDARREC1.Op.general 2865 79:general trip Yes
SDARREC1.OpOpn.general 2866 79:general Yes
SDARREC1.UnsCBCls.stVal 2867 79:UnsCBCls status Yes
SDARREC1.WtMstr.stVal 2868 79:WtMstr status Yes
SDARREC1.AROn.stVal 2869 79:AROn status Yes
SCBCILO1.EnaCls.stVal 3011 CB interlock:EnaCls status Yes
SCBCILO1.EnaOpn.stVal 3012 CB interlock:EnaOpn status Yes
SCBCILO1.ItlByPss.stVal 3013 CB interlock:ItlByPss status Yes
SCBCSWI1.Pos.stSeld 3014 CB Control: Yes
SCBCSWI1.PosA.stSeld 3015 CB Control: Yes
SCBCSWI1.PosB.stSeld 3016 CB Control: Yes
SCBCSWI1.PosC.stSeld 3017 CB Control: Yes
SCBXCBR1.BlkCls.stVal 3018 52:BlkCls status Yes
SCBXCBR1.BlkOpn.stVal 3019 52:BlkOpn status Yes
SCBXCBR1.CBOpCap.stVal 3020 52:CBOpCap status Yes
SCBXCBR1.Loc.stVal 3021 52:Loc status Yes
SCBXCBR1.OpCnt.stVal 3022 52:OpCnt status Yes
SCBXCBR1.Pos.stVal 3023 52:Pos status Yes
SCBXCBR1.PosCls.stVal 3024 52:PosCls status Yes
SCBXCBR1.PosOk.stVal 3025 52:PosOk status Yes
SCBXCBR1.PosOpn.stVal 3026 52:PosOpn status Yes
SPSCBR1.APwrAlm.stVal 3027 52CM:APwrAlm status Yes
SPSCBR1.APwrLO.stVal 3028 52CM:APwrLO status Yes
SPSCBR1.CBLifAlm.stVal 3029 52CM:CBLifAlm status Yes
SPSCBR1.ClsAlm.stVal 3030 52CM:ClsAlm status Yes
SPSCBR1.InaTmdCntA.stVal 3031 52CM:InaTmdCntA status Yes
SPSCBR1.InaTmdCntB.stVal 3032 52CM:InaTmdCntB status Yes
SPSCBR1.InaTmdCntC.stVal 3033 52CM:InaTmdCntC status Yes
SPSCBR1.InPosClsA.stVal 3034 52CM:InPosClsA status Yes
SPSCBR1.InPosClsB.stVal 3035 52CM:InPosClsB status Yes
SPSCBR1.InPosClsC.stVal 3036 52CM:InPosClsC status Yes
SPSCBR1.InPosOpnA.stVal 3037 52CM:InPosOpnA status Yes
SPSCBR1.InPosOpnB.stVal 3038 52CM:InPosOpnB status Yes
SPSCBR1.InPosOpnC.stVal 3039 52CM:InPosOpnC status Yes
SPSCBR1.InPresAlm.stVal 3040 52CM:InPresAlm status Yes
SPSCBR1.InPresLO.stVal 3041 52CM:InPresLO status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
