Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
30 RER620
Point List Manual
SPSCBR1.InSprCha.stVal 3042 52CM:InSprCha status Yes
SPSCBR1.InSprChStr.stVal 3043 52CM:InSprChStr status Yes
SPSCBR1.LonTmAlm.stVal 3044 52CM:LonTmAlm status Yes
SPSCBR1.OpCntA.stVal 3045 52CM:OpCntA status Yes
SPSCBR1.OpCntB.stVal 3046 52CM:OpCntB status Yes
SPSCBR1.OpCntC.stVal 3047 52CM:OpCntC status Yes
SPSCBR1.OpnAlm.stVal 3048 52CM:OpnAlm status Yes
SPSCBR1.OpNumAlm.stVal 3049 52CM:OpNumAlm status Yes
SPSCBR1.OpNumLO.stVal 3050 52CM:OpNumLO status Yes
SPSCBR1.PosClsA.stVal 3051 52CM:PosClsA status Yes
SPSCBR1.PosClsB.stVal 3052 52CM:PosClsB status Yes
SPSCBR1.PosClsC.stVal 3053 52CM:PosClsC status Yes
SPSCBR1.PosIvdA.stVal 3054 52CM:PosIvdA status Yes
SPSCBR1.PosIvdB.stVal 3055 52CM:PosIvdB status Yes
SPSCBR1.PosIvdC.stVal 3056 52CM:PosIvdC status Yes
SPSCBR1.PosOpnA.stVal 3057 52CM:PosOpnA status Yes
SPSCBR1.PosOpnB.stVal 3058 52CM:PosOpnB status Yes
SPSCBR1.PosOpnC.stVal 3059 52CM:PosOpnC status Yes
SPSCBR1.PresAlm.stVal 3060 52CM:PresAlm status Yes
SPSCBR1.PresLO.stVal 3061 52CM:PresLO status Yes
SPSCBR1.RmnLifPhA.stVal 3062 52CM:RmnLifPhA status Yes
SPSCBR1.RmnLifPhB.stVal 3063 52CM:RmnLifPhB status Yes
SPSCBR1.RmnLifPhC.stVal 3064 52CM:RmnLifPhC status Yes
SPSCBR1.RsAccAPwr.stVal 3065 52CM:RsAccAPwr status Yes
SPSCBR1.SprChaAlm.stVal 3066 52CM:SprChaAlm status Yes
CMMXU1.HiAlm.stVal 4701 "IA,IB,IC:HiAlm status" Yes
CMMXU1.HiWrn.stVal 4702 "IA,IB,IC:HiWrn status" Yes
CMMXU1.LoAlm.stVal 4703 Disabled "IA,IB,IC:LoAlm status" Yes
CMMXU1.LoWrn.stVal 4704 Disabled "IA,IB,IC:LoWrn status" Yes
RESCMMXU1.HiAlm.stVal 4709 IG:HiAlm status Yes
RESCMMXU1.HiWrn.stVal 4710 IG:HiWrn status Yes
VMMXU1.HiAlm.stVal 4715 "VA,VB,VC:HiAlm status" Yes
VMMXU1.HiWrn.stVal 4716 "VA,VB,VC:HiWrn status" Yes
VMMXU1.LoAlm.stVal 4717 "VA,VB,VC:LoAlm status" Yes
VMMXU1.LoWrn.stVal 4718 "VA,VB,VC:LoWrn status" Yes
XGGIO120.Ind1.stVal 5010 XGGIO120:Ind1 status Yes
XGGIO120.Ind2.stVal 5011 XGGIO120:Ind2 status Yes
XGGIO120.Ind3.stVal 5012 XGGIO120:Ind3 status Yes
XGGIO120.Ind4.stVal 5013 XGGIO120:Ind4 status Yes
XGGIO110.Ind1.stVal 5020 XGGIO110:Ind1 status Yes
XGGIO110.Ind2.stVal 5021 XGGIO110:Ind2 status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
