ABB RER620 - Page 37

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 31
Point List Manual
XGGIO110.Ind3.stVal 5022 XGGIO110:Ind3 status Yes
XGGIO110.Ind4.stVal 5023 XGGIO110:Ind4 status Yes
XGGIO110.Ind5.stVal 5024 XGGIO110:Ind5 status Yes
XGGIO110.Ind6.stVal 5025 XGGIO110:Ind6 status Yes
XGGIO110.Ind7.stVal 5026 XGGIO110:Ind7 status Yes
XGGIO110.Ind8.stVal 5027 XGGIO110:Ind8 status Yes
XGGIO110.SPCSO1.stVal 5030 XGGIO110:SPCSO1 status Yes
XGGIO110.SPCSO2.stVal 5031 XGGIO110:SPCSO2 status Yes
XGGIO110.SPCSO3.stVal 5032 XGGIO110:SPCSO3 status Yes
XGGIO110.SPCSO4.stVal 5033 XGGIO110:SPCSO4 status Yes
XGGIO100.SPCSO1.stVal 5040 XGGIO100:SPCSO1 status Yes
XGGIO100.SPCSO2.stVal 5041 XGGIO100:SPCSO2 status Yes
XGGIO100.SPCSO3.stVal 5042 XGGIO100:SPCSO3 status Yes
XGGIO100.SPCSO4.stVal 5043 XGGIO100:SPCSO4 status Yes
XGGIO100.SPCSO5.stVal 5044 XGGIO100:SPCSO5 status Yes
XGGIO100.SPCSO6.stVal 5045 XGGIO100:SPCSO6 status Yes
XGGIO105.Ind1.stVal 5070 XGGIO105:Ind1 status Yes
XGGIO105.Ind2.stVal 5071 XGGIO105:Ind2 status Yes
XGGIO105.Ind3.stVal 5072 XGGIO105:Ind3 status Yes
XGGIO105.Ind4.stVal 5073 XGGIO105:Ind4 status Yes
XGGIO105.Ind5.stVal 5074 XGGIO105:Ind5 status Yes
XGGIO105.Ind6.stVal 5075 XGGIO105:Ind6 status Yes
XGGIO105.Ind7.stVal 5076 XGGIO105:Ind7 status Yes
XGGIO105.Ind8.stVal 5077 XGGIO105:Ind8 status Yes
XGGIO105.SPCSO1.stVal 5080 XGGIO105:SPCSO1 status Yes
XGGIO105.SPCSO2.stVal 5081 XGGIO105:SPCSO2 status Yes
XGGIO105.SPCSO3.stVal 5082 XGGIO105:SPCSO3 status Yes
XGGIO105.SPCSO4.stVal 5083 XGGIO105:SPCSO4 status Yes
SPCGGIO1.SPCSO1.stVal 5090 SPCGGIO1:SPCSO1 status Yes
SPCGGIO1.SPCSO2.stVal 5091 SPCGGIO1:SPCSO2 status Yes
SPCGGIO1.SPCSO3.stVal 5092 SPCGGIO1:SPCSO3 status Yes
SPCGGIO1.SPCSO4.stVal 5093 SPCGGIO1:SPCSO4 status Yes
SPCGGIO1.SPCSO5.stVal 5094 SPCGGIO1:SPCSO5 status Yes
SPCGGIO1.SPCSO6.stVal 5095 SPCGGIO1:SPCSO6 status Yes
SPCGGIO1.SPCSO7.stVal 5096 SPCGGIO1:SPCSO7 status Yes
SPCGGIO1.SPCSO8.stVal 5097 SPCGGIO1:SPCSO8 status Yes
SPCGGIO1.SPCSO9.stVal 5098 SPCGGIO1:SPCSO9 status Yes
SPCGGIO1.SPCSO10.stVal 5099 SPCGGIO1:SPCSO10 status Yes
SPCGGIO1.SPCSO11.stVal 5100 SPCGGIO1:SPCSO11 status Yes
SPCGGIO1.SPCSO12.stVal 5101 SPCGGIO1:SPCSO12 status Yes
SPCGGIO1.SPCSO13.stVal 5102 SPCGGIO1:SPCSO13 status Yes
No events 61850 Path IOA Disabled Description Multiplier Interrogation
