1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 33
Point List Manual
XGGIO115.InOpnC.stVal 5522 XGGIO115:InOpnC status Yes
XGGIO115.LstPoleOp.stVal 5523 XGGIO115:LstPoleOp status Yes
XGGIO115.PolSwVol.stVal 5524 XGGIO115:PolSwVol status Yes
XGGIO115.Time1.stVal 5525 XGGIO115:Time1 status Yes
XGGIO115.Time2.stVal 5526 XGGIO115:Time2 status Yes
XGGIO115.Time3.stVal 5527 XGGIO115:Time3 status Yes
XGGIO115.Time4.stVal 5528 XGGIO115:Time4 status Yes
XGGIO115.Time5.stVal 5529 XGGIO115:Time5 status Yes
XGGIO115.Time6.stVal 5530 XGGIO115:Time6 status Yes
EFLPTOC3.Op.general 6044 50SEF:general trip
EFLPTOC3.Str.general 6045 50SEF:general pickup
FRPFRC1.Op.general 6053 FRPFRC1:general trip
FRPFRC2.Op.general 6054 FRPFRC2:general trip
FRPTOF1.Op.general 6059 FRPTOF1:general trip
FRPTOF2.Op.general 6060 FRPTOF2:general trip
FRPTRC1.Str.general 6065 Freq1:general pickup
FRPTRC2.Str.general 6066 Freq2:general pickup
FRPTUF1.Op.general 6071 FRPTUF1:general trip
FRPTUF2.Op.general 6072 FRPTUF2:general trip
INRPHAR1.Str.general 6079 INRPHAR1:general pickup
INRPHAR1.Str.phsA 6080 INRPHAR1:phase A pickup
INRPHAR1.Str.phsB 6081 INRPHAR1:phase B pickup
INRPHAR1.Str.phsC 6082 INRPHAR1:phase C pickup
LSHDPTRC1.Op.general 6092 LSHDPTRC1:general trip
LSHDPTRC1.Str.general 6093 LSHDPTRC1:general pickup
LSHDPTRC2.Op.general 6094 LSHDPTRC2:general trip
LSHDPTRC2.Str.general 6095 LSHDPTRC2:general pickup
MVGAPC2.Op.general 6115 MVGAPC2:general trip
MVGAPC2.Str.general 6116 MVGAPC2:general pickup
NSPTOV1.Op.general 6125 47-1:general trip
NSPTOV1.Str.general 6126 47-1:general pickup
NSPTOV2.Op.general 6127 47-2:general trip
NSPTOV2.Str.general 6128 47-2:general pickup
PDNSPTOC1.Op.general 6129 PDNSPTOC1:general trip
PDNSPTOC1.Str.general 6130 PDNSPTOC1:general pickup
PHIZ1.Op.general 6160 HIZ:general trip
PHIZ1.Str.general 6161 HIZ:general pickup
PSPTOV1.Op.general 6225 59PS-1:general trip
PSPTOV1.Str.general 6226 59PS-1:general pickup
PSPTOV2.Op.general 6227 59PS-2:general trip
PSPTOV2.Str.general 6228 59PS-2:general pickup
No events 61850 Path IOA Disabled Description Multiplier Interrogation
