Section 2 1MAC302441-MB A
IEC 60870-5-101/104 data mappings
34 RER620
Point List Manual
PTGAPC1.Op.general 6237 PTGAPC1:general trip
PTGAPC1.Str.general 6238 PTGAPC1:general pickup
PTGAPC2.Op.general 6239 PTGAPC2:general trip
PTGAPC2.Str.general 6240 PTGAPC2:general pickup
ROVPTOV1.Op.general 6241 59N-1:general trip
ROVPTOV1.Str.general 6242 59N-1:general pickup
ROVPTOV2.Op.general 6243 59N-2:general trip
ROVPTOV2.Str.general 6244 59N-2:general pickup
SCCBRBRF1.Str.general 6247 50BFT:general pickup
SDARREC1.Op.phsA 6248 79:phase A trip
SDARREC1.Op.phsB 6249 79:phase B trip
SDARREC1.Op.phsC 6250 79:phase C trip
SDPHLPTOC1.Op.general 6251 67/51P-1:general trip
SDPHLPTOC1.Op.phsA 6252 67/51P-1:phase A trip
SDPHLPTOC1.Op.phsB 6253 67/51P-1:phase B trip
SDPHLPTOC1.Op.phsC 6254 67/51P-1:phase C trip
SDPHLPTOC1.Str.general 6255 67/51P-1:general pickup
SDPHLPTOC1.Str.phsA 6256 67/51P-1:phase A pickup
SDPHLPTOC1.Str.phsB 6257 67/51P-1:phase B pickup
SDPHLPTOC1.Str.phsC 6258 67/51P-1:phase C pickup
SDPHLPTOC2.Op.general 6259 67/51P-2:general trip
SDPHLPTOC2.Op.phsA 6260 67/51P-2:phase A trip
SDPHLPTOC2.Op.phsB 6261 67/51P-2:phase B trip
SDPHLPTOC2.Op.phsC 6262 67/51P-2:phase C trip
SDPHLPTOC2.Str.general 6263 67/51P-2:general pickup
SDPHLPTOC2.Str.phsA 6264 67/51P-2:phase A pickup
SDPHLPTOC2.Str.phsB 6265 67/51P-2:phase B pickup
SDPHLPTOC2.Str.phsC 6266 67/51P-2:phase C pickup
SEQRFUF1.Str.general 6267 60:general pickup
SPHHPTOC1.Op.general 6268 SPHHPTOC1:general trip
SPHHPTOC1.Op.phsA 6269 SPHHPTOC1:phase A trip
SPHHPTOC1.Op.phsB 6270 SPHHPTOC1:phase B trip
SPHHPTOC1.Op.phsC 6271 SPHHPTOC1:phase C trip
SPHHPTOC1.Str.general 6272 SPHHPTOC1:general pickup
SPHHPTOC1.Str.phsA 6273 SPHHPTOC1:phase A pickup
SPHHPTOC1.Str.phsB 6274 SPHHPTOC1:phase B pickup
SPHHPTOC1.Str.phsC 6275 SPHHPTOC1:phase C pickup
SPHIPTOC1.Op.general 6284 SPHIPTOC1:general trip
SPHIPTOC1.Op.phsA 6285 SPHIPTOC1:phase A trip
SPHIPTOC1.Op.phsB 6286 SPHIPTOC1:phase B trip
SPHIPTOC1.Op.phsC 6287 SPHIPTOC1:phase C trip
No events 61850 Path IOA Disabled Description Multiplier Interrogation
