ABB RER620 - Page 41

1MAC302441-MB A Section 2
IEC 60870-5-101/104 data mappings
RER620 35
Point List Manual
SPHIPTOC1.Str.general 6288 SPHIPTOC1:general pickup
SPHIPTOC1.Str.phsA 6289 SPHIPTOC1:phase A pickup
SPHIPTOC1.Str.phsB 6290 SPHIPTOC1:phase B pickup
SPHIPTOC1.Str.phsC 6291 SPHIPTOC1:phase C pickup
SPHLPTOC1.Op.general 6292 51P:general trip
SPHLPTOC1.Op.phsA 6293 51P:phase A trip
SPHLPTOC1.Op.phsB 6294 51P:phase B trip
SPHLPTOC1.Op.phsC 6295 51P:phase C trip
SPHLPTOC1.Str.general 6296 51P:general pickup
SPHLPTOC1.Str.phsA 6297 51P:phase A pickup
SPHLPTOC1.Str.phsB 6298 51P:phase B pickup
SPHLPTOC1.Str.phsC 6299 51P:phase C pickup
SPHLPTOC2.Op.general 6300 50P-1:general trip
SPHLPTOC2.Op.phsA 6301 50P-1:phase A trip
SPHLPTOC2.Op.phsB 6302 50P-1:phase B trip
SPHLPTOC2.Op.phsC 6303 50P-1:phase C trip
SPHLPTOC2.Str.general 6304 50P-1:general pickup
SPHLPTOC2.Str.phsA 6305 50P-1:phase A pickup
SPHLPTOC2.Str.phsB 6306 50P-1:phase B pickup
SPHLPTOC2.Str.phsC 6307 50P-1:phase C pickup
SPHPTOV1.Op.general 6308 59-1:general trip
SPHPTOV1.Str.general 6309 59-1:general pickup
SPHPTOV2.Op.general 6310 59-2:general trip
SPHPTOV2.Str.general 6311 59-2:general pickup
SPHPTOV3.Op.general 6312 59-3:general trip
SPHPTOV3.Str.general 6313 59-3:general pickup
SPHPTUV1.Op.general 6314 27-1:general trip
SPHPTUV1.Str.general 6315 27-1:general pickup
SPHPTUV2.Op.general 6316 27-2:general trip
SPHPTUV2.Str.general 6317 27-2:general pickup
SPHPTUV3.Op.general 6318 27-3:general trip
SPHPTUV3.Str.general 6319 27-3:general pickup
SRGAPC1.Op.general 6320 SRGAPC1:general trip
SRGAPC1.Str.general 6321 SRGAPC1:general pickup
SRGAPC2.Op.general 6322 SRGAPC2:general trip
SRGAPC2.Str.general 6323 SRGAPC2:general pickup
TOFGAPC1.Op.general 6331 TOFGAPC1:general trip
TOFGAPC1.Str.general 6332 TOFGAPC1:general pickup
TOFGAPC2.Op.general 6333 TOFGAPC2:general trip
TOFGAPC2.Str.general 6334 TOFGAPC2:general pickup
TONGAPC1.Op.general 6335 TONGAPC1:general trip
No events 61850 Path IOA Disabled Description Multiplier Interrogation
