21
3. Phase
The programmed phase value is displayed.
The phase shift to be programmed can be selected from the tables below.
Three-phase connection (Phase to phase)
Voltage is measured between L2 and L3.
L1
Direct
L1
Inverted
L2
Direct
L2
Inverted
L3
Direct
L3
Inverted
90
270
330
150
210
30
CT Connection Connection Drawing Phase to be programmed
