Figure 55. Mixed Mounting of 1 FCI and 4+4+4 S800M I/O MTUs (Compact and
Extended) and S800L I/O Modules
1169 mm (46”)
84mm
58mm
85.8 mm (3.4”)
162mm (6.37”)
110mm (4.33”)
(3.3”)
(2.3”)
Terminator
TB807
123456789 11 1213141510 16
Status
S12345678910111213141516
123456789 11 1213141510 16
Status
S12345678910111213141516
123456789 11 1213141510 16
Status
S12345678910111213141516
123456789 11 1213141510 16
Status
S1234567891011121314151 6
120 mm (4.72”)
Mounting Section 2 Product Description
108 3BSE015969-600 A
By using extension cable(s) a very flexible mounting arrangement is possible,
adapting to required panel or cabinet layout. The maximum length of an electrical
ModuleBus should not be more when 2.5 m (100”)
Figure 56. I/O Station in Small Groups
Cable Adaptor, out
TB805
Cable Adaptor, in
TB806
Term ina to r
TB807
Digital Inputs
Analog Inputs
Analog Outputs Digital Outputs
TK801V0xx
123456789 11 12 13141510 16
Status
S12345678910111213141516
To Next Page
