ModuleBus Items Section 2 Product Description
40 3BSE015969-600 A
ModuleBus Items
The ModuleBus supports up to 8 cluster, one base cluster and up to 7 I/O cluster,
connected to each other via optical cables, Optical ModuleBus Modems and
a ModuleBus Optical port module. The cluster is built up by MTUs and/or S800L
modules. At the last, MTU or S800L modules bus outlet a terminator module,
TB807, must be inserted.
Mounting
Kit
Used for horizontal mounting of CI801, CI840 and TB840 on a vertical
DIN-rail.
Horizontal
Mounting
Profile
Mounting profile with one DIN-rail and one cable duct.
(1) Connector is not enclosed.
(2) The three cable plugs are enclosed, see Table 4.
(3) Connector is not enclosed. Three connectors are needed, see Table 4.
Table 4. Cable Connectors for TU813 and TU814, Supplied by Phoenix Contact
Part No Name
Cable plug TU813 1809792 MSTBC 2.5/8-STZF-5.08
Cable plug TU814 1808890 MSTBC 2.5/10-ST-5.08
Crimp snap in
connector
1879531 MSTBC-MT 0.2-0.5
3190564 MSTBC-MT 0.5-1.0
3190551 MSTBC-MT 1.5-2.5
Crimping tool 1204038 CRIMPFOX MT 2.5
Remove insulation tool 1204384 QUICK WIREFOX 6
Table 3. S800M I/O Termination Units (Continued)
Module
Type
Description
