Section 2 Product Description Module Termination
3BSE015969-600 A 39
TU842 Redundant horizontal MTU, 3
*
16 + 2
*
4 terminals, 50 V for redundant
I/O modules
TU843 Redundant vertical MTU, 3
*
16 + 2
*
4 terminals, 50 V for redundant I/O
modules
TU844 Redundant horizontal MTU, 2
*
16 + 2
*
4 terminals, 50 V for redundant
I/O modules. 8 positions for shuntsticks for current or voltage signals.
TU845 Redundant vertical MTU, 2
*
16 + 2
*
4 terminals, 50 V for redundant I/O
modules. 8 positions for shuntsticks for current or voltage signals.
TU850 Extended MTU, 2x8 current limited sensor power + 16 signal + 2x4
fused power connections terminals, 50 V.
TU851 Extended MTU, up to 16 isolated channels, 250 V.
TU852 Redundant Horizontal MTU, two 25 pin D-sub Connectors for field
connection, 50V.
TU854 Redundant Horizontal MTU, 25 pin D-sub Connector for field
connection and individual shunt sticks, 50V.
TU890 Compact MTU, I.S. applications, 50 V. For use with I/O modules with
Intrinsic Safety interfaces.
TU891 Compact MTU, Non I.S. applications, 50 V. For use with I/O modules
with Intrinsic Safety interfaces in non-Intrinsic Safety applications.
TY801K01 Set of 8 pcs. of shunt sticks for current or voltage signals together with
AI845 or AI880/AI880A and TU844 or TU845.
TY804K01 Set of 8 pcs. of shunt sticks for NAMUR signals together with DP840
and TU844 or TU845.
TY820 Temperature sensor with 4-wire connection, and used together with
AI835 and AI843.
Table 3. S800M I/O Termination Units (Continued)
Module
Type
Description
