Module Termination Section 2 Product Description
38 3BSE015969-600 A
TU830/
TU830V1
Extended MTU, 3
*
16 + 2
*
4 terminals, 50 V. Typically used with 24/48
V d.c binary and -20 - +20 mA analog modules. Provides terminals for
field power distribution.
TU831/
TU831V1
Extended MTU, 8
*
2 terminals, 250 V. Typically used with 120/230 V
d.c/a.c binary modules. Provides terminals for field power distribution.
TU833 Extended MTU, 3
*
16 + 2
*
4 spring-case terminals, 50 V. Typically used
with 24/48 V d.c binary and -20 - +20 mA analog modules. Provides
terminals for field power distribution.
TU834 Extended MTU, 2x16 terminals, 50 V, 8 channels with individual shunt
sticks
TU835/
TU835V1
Extended MTU, 4*2 groups + 2*4 power terminals, 50 V,
individually fused per channel. Channel wise fused transducer power
outlets. Usable for 2-wire transmitters.
TU836/
TU836V1
Extended MTU, 2*4 groups + 2*6 power terminals, 250 V,
individually fused per channel. For loads where the power supply
always is taken from the MTU.
TU837/
TU837V1
Extended MTU, 2*4 groups + 2*6 power return terminals, 250 V,
fused. For loads where the power supply always is taken from the
MTU or without the power supply per channel.
TU838 Extended MTU, 2*4 groups + 2*4 power return terminals, 50 V, fused.
AI: Each channel includes terminals for current and voltage, fused
power outlet and signal return. Usable for 2-, 3- and 4-wire
transmitters.
DI: Each channel includes terminals for 16 signals, 16 signal returns
and 16 power outlets. The power outlets are wired in pairs. Each pair
has a common fuse.
TU839 Extended MTU, 3x2 groups + 2x3 power return terminals,
250 V, fused.
Table 3. S800M I/O Termination Units (Continued)
Module
Type
Description
