PROFIBUS CI801 Section 3 Technical Data and Performance
128 3BSE015969-600 A
Table 25. Calculation of Number of Modules on CI801
Module
Type
User
Parameters
Input
Bytes
Output
Bytes
Number
of
Modules
Sum
User Para-
meters
Sum
Input
Bytes
Sum
Output
Bytes
AI801 13 17 0
AI810 13 17 0
AI820 9 9 0
AI825 9 9 0
AI830/
AI830A
12 17 0
AI835 15 17 0
AI835A 16 17 2
AI843 16 20 2
AI815,
AI845
13 17 0
AI890 13 17 0
AI893 15 17 0
AI895 13 17 0
AO801 17 1 16
AO810/
AO810V2
17 1 16
AO820 11 1 8
AO815,
AO845/

AO845A
18 1 16
AO890 17 1 16
AO895 17 1 16
