PROFIBUS CI840 Section 3 Technical Data and Performance
136 3BSE015969-600 A
DI801 7 4 0
DI802 6 2 0
DI803 6 2 0
DI810 7 4 0
DI811 7 4 0
DI814 7 4 0
DI818 9 8 0
DI820 6 2 0
DI821 6 2 0
DI828 7 4 0
DI825
(1)
9 2 0
DI830
(1)
14 4 0
DI831
(1)
14 4 0
DI840 13 4 -
DI885
(1)
10 2 0
DI890 7 2 0
DO801 10 2 2
DO802 7 1 1
DO810 10 2 2
DO814 10 2 2
DO815 8 1 1
DO818 16 4 4
Table 27. Calculation of Number of Modules on CI840 (Continued)
Module
Type
User
Parameters
Input
Bytes
Output
Bytes
Number
of
Modules
Sum
User Para-
meters
Sum
Input
Bytes
Sum
Output
Bytes
