Section 3 Technical Data and Performance S800 I/O Station Data Scanning
3BSE015969-600 A 139
AI843 0.40 - 0.40 0.80
AI815, AI845 3.00 - 3.00 6.00
AO801, AO810, AO810V2,
AO890, AO895
1.20 1.20 1.20 -
AO820 0.60 0.60 0.60 -
AO815, AO845, AO845A 1.20 - 1.20 2.40
DI801, DI810, DI811, DI814,
DI820, DI821, DI890
0.43 0.43 0.50 -
DI818 0.86 - 1.0 -
DI802, DI803, DI828 0.43 - 0.50 -
DI840 0.43 - 0.50 1.00
DI830, DI831, DI885 - 0.43 - -
DO801, DO810, DO814,
DO815, DO820, DO82
0.43 0.43 0.50 -
DO818 0.86 - 1.0 -
DO802, DO828 0.43 - 0.50 -
DO840 0.43 - 0.50 1.00
DO890 0.43 0.43 0.50 -
DP820 1.72 1.72 2.09 -
DP840 3.00 - 3.00 6.00
Engineered drives - 1.72 - -
Table 28. I/O Scan Cycle Time in the FCI (Continued)
Module Type
Execution Time Used in ms
CI801
CI810,
CI820
CI840
Single I/O
Redundant
I/O pair
