ABB S800 - Page 152

Power Supply and Cooling Requirements Section 3 Technical Data and Performance
152 3BSE015969-600 A
DO840 130 mA - 200 mA +
channel
load
(6)
4.3 14 55/40C (131/104F)
(2)
DO880 45 mA 55 mA 10 mA +
channel
load
(6)(8)
5.6
(9)
19 55/40C (131/104F)
(2)
DO890 150 mA - 360 mA 4.4 15 55/40C (131/104F)
(2)
DP820 120 mA -
(6)
2.5 8.5 55/40C (131/104F)
(2)
DP840 115 mA - 70 mA
(6)
4.0 14 55/40C (131/104F)
(2)
TB810 100 mA 20 mA - 0.5 1.7 55C/(131F)
TB811 100 mA 20 mA - 0.5 1.7 55C/(131F)
TB820/
TB820V2
- - 100 mA 6.0 20 55C/(131F)
TB825 - - 96 mA 2.3 7.8 55C/(131F)
TB826 - - 92 mA 2.2 7.8 55C/(131F)
TB840 - - 120 mA
(4)
6.0 20 55/40C
(131/104F)
(10)
TB842 100 mA 20 mA - 0.5 1.7 55C/(131F)
SD831 - - - 10/8
(11)
34/27 55C/(131F)
(12)
SD832 - - - 14/13
(11)
47/44 55C/(131F)
(12)
SD833 - - - 24/22
(11)
81/75 55C/(131F)
(12)
SD834 40/31
(11)
136/105 55C/(131F)
(12)
Table 32. I/O Station Power and Cooling (Typical) Values (Continued)
Device
5 Volts
ModuleBus
24 Volts
ModuleBus
24 Volts
External
Power
Dissipation
(Watts)
Cooling
Load
(1)
(BTU/H
Typical)
Maximum Ambient
Temperature
