Introduction Section 2 Product Description
22 3BSE015969-600 A
Figure 2. I/O Station Overview
Controller
Fieldbus
Optical
Optical ModuleBus Modem
I/O Module
FCI
ModuleBus
ModuleBus Optical Port
Base Cluster
I/O Cluster
I/O Station
Electrical
ModuleBus
I/O Cluster
Base Cluster
