Section 2 Product Description I/O Modules
3BSE015969-600 A 27
S800 I/O modules per station connected via AF100 24
(2)
S800 I/O modules per station connected via PROFIBUS.
Supported I/O modules types.
See Chapter 3,
Technical Data and
Performance
(1) If other than S800 I/O stations are used on the same Advant Fieldbus 100, the maximum
number of S800 I/O stations must be reduced with a corresponding number of stations.
(2) Without Optical ModuleBus Expansion the maximum number is 12.
Table 1. The max. I/O Configuration of S800 I/O Connected to Advant Fieldbus 100
and PROFIBUS. (Continued)
Item Max. No.
