ABB S800 - Page 46

I/O Modules Section 2 Product Description
46 3BSE015969-600 A
DO801 L Digital Output 24 V d.c. 0.5 A protected,
1*16 channels
(2)

Rated insulation voltage 50 V
DO802 L Digital Output Relay 8*1 channels, 24-230 V a.c./110
V d.c. 2 A cos   d.c. < 60 W.
Varistor protected
Rated insulation voltage 250 V.
DO810 Digital Output 24 V d.c. 0.5 A protected,
2*8 channels
(3)
Rated insulation voltage 50 V.
DO814 Digital Output 24 V d.c. 0.5 A protected,
2*8 channels
(3)
, current sink
Rated insulation voltage 50 V
DO815
(8)
Digital Output 24 V d.c. 2 A protected,
2*4 channels.
Rated insulation voltage 50 V.
DO818 Digital Output 24 V d.c. 0.5 A protected,
2*16 channels
(4)
Rated insulation voltage 50 V.
DO820 Digital Output Relay 8*1 channels 24-230 V a.c.
3 A cos 0.4 d.c. < 42W. Varistor protected
Rated insulation voltage 250 V.
DO821 Digital Output Relay 8*1 normally closed channels
24-230 V a.c./d.c. 3 A cos 0.5 d.c. < 42 W
Varistor protected
Rated insulation voltage 250 V
DO828 Digital Output Relay 16*1 channels
125Vd.c./250V a.c.
Rated isolation voltage 250 V.
Table 6. S800 Digital Modules (Continued)
Module
Type
Type
(1)
Description
