ABB SACE Emax 2 Series Manual

1
ABB
E1.2 - E2.2 - E4.2 - E6.2 - XT7 - XT7M F
32 4
2
3
3
2
3
2
3
2
E1.2 - XT7 - XT7M F
E2.2 - E4.2 - E6.2 F
Staccare alimentazione dell’Ekip Supply.
Disconnect power from the Ekip Supply module.
Die Speisung von Ekip Supply ausschalten.
Debrancher l'alimentation de l’Ekip Supply.
Desconectar la alimentación del Ekip Supply.
断开Ekip Supply的电源.
1
Modulo opzionale aggiuntivo
Additional optional module
Wahlweises Zusatzmodul
Module optionnel supplémentaire
Módulo opcional adicional
附加可选模块
Modulo opzionale già presente
Optional module already present
Wahlweises Modul schon vorhanden
Module optionnel déjà présent
Módulo opcional ya presente
可选模块已存在

ABB SACE Emax 2 Series Specifications

General

Breaking capacity	Up to 150kA
Number of poles	3 or 4 poles
Communication protocols	Modbus, Profibus
Standards	IEC 60947-2
Type	Air circuit breaker
Mounting	Fixed, Withdrawable
