31
The following example of an interlocking con-
figuration relates to the figure on page xx.
At first INTERLOCK function is selected.
Channel 10 is called up.
The display is set to 010-, which is stored in the
memory.
Channel 10 now activates interlocking Line 1.
Channel 8 is called up.
The display is set at 2102, which is stored in the
memory.
Channel 10 now interlocks whole channel 8 (via
the interlocking line 1 ) at the same time channel
8 activates interlocking line 2.
Then channel 7 is called up.
The display is set at 110-, which is stored in the
memory.
Channel 10 now interlocks the reflash A of
channel 7 via interlocking Line 1.
Then channel 5 is called up.
The display is set at 120-, which is stored in the
memory.
Channel 10 now interlocks channel 8 which
interlocks the channel reflash type A of channel
5 via interlocking line 2.
Selection of
annunciator SPA bus
slave address
The parameter selector push-button ↓ is repeat-
edly pressed until the LED marked MODULE
starts glowing. The cursor is moved to the first
two digits from the left of the display, using the
cursor control push-button →. The SPA bus
slave number (01...99) is selected for the annun-
ciator unit with the data value selector push-
button ↑. The chosen slave number is entered
into the parameter memory by pressing the
enter control push-button.
NOTE!
No slave number is needed if the annunciator
unit is not connected to a higher level system.
Selection of alarm
sequence type
The selectable alarm sequences are illustrated on
page xx. To select the chosen alarm sequence the
parameter selector push-button ↓ is repeatedly
pressed until the LED marked MODULE starts
glowing. Using the cursor control push-button
→, the cursor is moved to the third digit, seen
from the left, which indicates the selectable
alarm sequence types as follows:
0 = ISA A, automatic reset
1 = ISA A-1, automatic reset
2 = ISA M-1, manual reset
3 = ISA R-1, indication on return to normal
4 = DIN 19235, indication on return to normal
All sequence types but ISA A requires a separate
reset of the audible alarm. The chosen sequence
is selected with the data value selector push-
button ↑ and stored in the parameter memory
with the enter command push-button.
