ABB SACO 16D1 - Channel Interlocking Scheme

35
Channel inter-
locking scheme
INTERLOCKING GROUPS
1 2 3 4 5 6 7 8
Channel 1/__
Function 1
Function 2
Channel 2/__
Function 1
Function 2
Channel 3/__
Function 1
Function 2
Channel 4/__
Function 1
Function 2
Channel 5/__
Function 1
Function 2
Channel 6/__
Function 1
Function 2
Channel 7/__
Function 1
Function 2
Channel 8/__
Function 1
Function 2
Channel 9/__
Function 1
Function 2
Channel 10/__
Function 1
Function 2
Channel 11/__
Function 1
Function 2
Channel 12/__
Function 1
Function 2
Channel 13/__
Function 1
Function 2
Channel 14/__
Function 1
Function 2
Channel 15/__
Function 1
Function 2
Channel 16/__
Function 1
Function 2
TYPE OF INTERLOCKING
0 = interlocking output
1 = reflash A interlocking input
2 = channel interlocking input
Alarm module No___
Fig. 34. Channel interlocking scheme for programming.
