ABB TA 450 SU V1000 - Auslösekennlinien; Tripping Characteristics; Caratteristiche DI Intervento; Curvas Características de Disparo

31
ABB STOTZ-KONTAKT
2CDC 106 008 M5703
D
Auslösekennlinien
E
Tripping characteristics
F
Courbes de déclenchement
S
Utlösningskurvor
I
Caratteristiche di intervento
SP
Curvas características
de disparo
RUS
Характеристики
срабатывания
three
pole
4)
two pole
3)
40.0 ... 50.0 ... 60.0 A
Tripping time
2)
Multiples of rated
current
1)
3 x Ie 6 x Ie
7.2 x Ie
min
three pole
4)
30.0 s 17.3 s 15.7 s
Multiples of rated current
1)
Tripping time
2)
40.0 A
two pole
3)
18.0 s
11.0 s
10.1 s
max
three pole
4)
40.0 s 25.0 s 23.2 s
60.0 A
two pole
3)
22.0 s 13.5 s 12.6 s
three
pole
4)
two pole
3)
Multiples of rated current
1)
Tripping time
2)
55.0 ... 68.0 ... 80.0 A
Tripping time
2)
Multiples of rated
current
1)
3 x Ie 6 x Ie
7.2 x Ie
min
three pole
4)
29.5 s 18.3 s 16.1 s
55.0 A
two pole
3)
19.4 s
11.0 s
9.9 s
max
three pole
4)
44.5 s 28.1 s 26.4 s
80.0 A
two pole
3)
22.4 s 13.8 s 12.9 s
1) 2) 3) 4) 5)
Vielfaches vom Nennstrom Auslösezeit 2-polig 3-polig Sicherung
Multiple du courant de reglage Temps de déclenchement 2 broches 3 broches Fusible
Multipelfaktor för utlösningsström Utlösningstid 2-polig 3-polig Säkring
Multiplo della corrente di regolazione Tempo di apertura Bipolare Tripolare Fusibile
Múltiplos de la intensidad aplicada tiempo de disparo de 2 polos de 3 polos Fusible
